Defender Electric Diagrams. Manual - part 166

C1104

CONNECTOR

DEFENDER 1999 MY

Chassis harness to tail door
harness

Female
TIN-PLATE

RH side of taildoor, behind
trim panel

P5817

C1104

C1103

Cav

Col

CCT

1

B

ALL

CONNECTOR

C1105

DEFENDER 1999 MY

Switch - Park - Rear wiper

Female
BLACK

RH side of taildoor, behind
trim panel

C1105

P5647

Cav

Col

CCT

1

NLG

ALL

2

G

ALL

3

B

ALL

C1186

CONNECTOR

DEFENDER 1999 MY

Fuel Tank - Td5

Female
BLACK

Above fuel tank

P5782

C1186

Cav

Col

CCT

1

WP

9

2

GB

9

3

SB

9

4

B

9

CONNECTOR

C1194

DEFENDER 1999 MY

Switch - Wash / wipe - Rear
screen

Female
RED

Behind centre of fascia

P5656

C1196

C1194

C0093

C0074

C1195

C0089

C1197

Cav

Col

CCT

1

RLG

ALL
