Defender Electric Diagrams. Manual - part 150

C0508

CONNECTOR

DEFENDER 1999 MY

Relay - ABS - Return pump

Female
BLACK

Beneath RH seat

P5596

C1268

C0019

C0508

C0215

C0063

Cav

Col

CCT

1

NR

ALL

2

WO

12

3

NW

12

4

B

12

CONNECTOR

C0512

DEFENDER 1999 MY

Lamp - Fog guard - Rear -
RH

Female
ORANGE

RH side of taildoor, behind
trim panel

P5601

C0512

C0455

C0704

C1102

Cav

Col

CCT

1

B

ALL

2

RY

ALL

C0515

CONNECTOR

DEFENDER 1999 MY

Lamp - Fog guard - Rear -
LH

Female
ORANGE

RH side of tail door

P5600

C0472

C0515

C0139

C0138

Cav

Col

CCT

1

B

ALL

2

RY

ALL

CONNECTOR

C0516

DEFENDER 1999 MY

Sensor - ABS - Front - LH

Male
NATURAL

LH side of engine
compartment

P5574

C0516

Cav

Col

CCT

1

W

12

2

W

12
