C0289

CONNECTOR

DEFENDER 1999 MY

Header

Female
GREY

Behind centre of fascia

P5663

C0290

C0289

C0292

Cav

Col

CCT

1

B

4

2

B

ALL

3

B

25

4

B

12

6

B

ALL

7

B

ALL

8

B

28

9

OW

ALL

10

OW

15

Cav

Col

CCT

11

B

15

13

B

ALL

14

B

ALL

15

B

ALL

16

B

ALL

17

B

ALL

18

B

ALL

19

B

ALL

20

B

ALL

CONNECTOR

C0290

DEFENDER 1999 MY

Header

Female
GREY

Behind centre of fascia

P5663

C0290

C0289

C0292

Cav

Col

CCT

1

RO

ALL

2

RO

ALL

3

RO

ALL

4

RO

ALL

5

RO

25

6

RO

27

7

RO

27

8

RO

ALL

9

B

ALL

Cav

Col

CCT

10

B

ALL

11

B

ALL

12

B

ALL

13

RO

ALL

14

RO

ALL

15

RO

ALL

16

RO

1

17

RO

27

18

RO

27

C0292

CONNECTOR

DEFENDER 1999 MY

Header

Female
BLUE

Behind centre of fascia

P5663

C0290

C0289

C0292

Cav

Col

CCT

1

GR

ALL

2

GR

ALL

3

GR

ALL

4

GR

ALL

5

GR

ALL

6

GR

ALL

7

GY

ALL

8

GY

ALL

9

GY

ALL

11

B

ALL

Cav

Col

CCT

12

B

1

13

B

ALL

14

B

ALL

15

GW

ALL

16

GW

ALL

17

GW

ALL

18

GW

ALL

19

GW

ALL

20

GW

ALL

CONNECTOR

C0303

DEFENDER 1999 MY

ECU - Delay - Windscreen
wiper

Female
BLACK

Beneath centre console

P5644

C0303

C0547

Cav

Col

CCT

1

WG

ALL

2

YLG

ALL

4

B

ALL

5

NLG

ALL

6

LGB

ALL

8

WG

ALL
