C0113

CONNECTOR

DEFENDER 1999 MY

Fuel tank - Non Td5

Female
BLACK

Above fuel tank

P5781

C0113

Cav Col CCT

1

GB

22

2

SB

22

3

B

22

4

WP

22

CONNECTOR

C0114

DEFENDER 1999 MY

Fuel tank - Td5

Female
BLACK

Above fuel tank

P5780

C0114

Cav

Col

CCT

1

WP

7

1

WP

8

2

GB

7

2

GB

8

3

SB

7

3

SB

8

4

B

7

4

B

8

C0116

CONNECTOR

DEFENDER 1999 MY

Diode

Female
BLACK

Behind instrument pack

P5654

C0116

Cav

Col

CCT

1

SR

ALL

2

WY

ALL

CONNECTOR

C0121

DEFENDER 1999 MY

Lamp - Tail - LH

Female
BLACK

LH rear of vehicle

P5520

C0121

Cav

Col

CCT

1

B

ALL

2

GP

ALL

3

RB

ALL
