C0092

CONNECTOR

DEFENDER 1999 MY

Radio / cassette player

Female
BROWN

Behind centre of fascia

P5662

C0098

C0092

Cav

Col

CCT

3

BK

ALL

4

BR

ALL

5

BY

ALL

6

BO

ALL

CONNECTOR

C0093

DEFENDER 1999 MY

Switch - Headlamp levelling

Female
NATURAL

Behind centre of fascia

P5656

C1196

C1194

C0093

C0074

C1195

C0089

C1197

Cav

Col

CCT

2

UY

27

3

B

27

4

RO

27

5

RO

27

C0094

CONNECTOR

DEFENDER 1999 MY

Switch - Ignition

Female
NATURAL

Behind instrument pack

Cav

Col

CCT

1

W

ALL

CONNECTOR

C0096

DEFENDER 1999 MY

Switch - Hazard warning

Female
BLACK

Adjacent steering column

P5652

C0096

C1036

C1037

Cav

Col

CCT

1

BR

ALL

2

LGN

ALL

3

GR

ALL

4

GW

ALL

5

LG

ALL

7

PN

ALL

8

WG

ALL
