Defender Electric Diagrams. Manual - part 125

C0075

CONNECTOR

DEFENDER 1999 MY

Switch - Brake pedal

Female
NATURAL

Adjacent pedal box

P5564

C0075

C0029

C1264

C0667

C1265

Cav

Col

CCT

1

GY

ALL

CONNECTOR

C0089

DEFENDER 1999 MY

Cigar lighter

Female
RED

Adjacent steering column

P5656

C1196

C1194

C0093

C0074

C1195

C0089

C1197

Cav

Col

CCT

1

B

ALL

2

PG

ALL

C0090

CONNECTOR

DEFENDER 1999 MY

Switch - Ignition

Female
RED

Behind instrument pack

Cav

Col

CCT

1

WR

ALL

CONNECTOR

C0091

DEFENDER 1999 MY

Switch - Handbrake

Female
BLACK

Base of handbrake lever

P5779

C0091

Cav

Col

CCT

3

WY

ALL
