C0068

CONNECTOR

DEFENDER 1999 MY

Resistor - Blower motor

Female
WHITE

Behind RH side of fascia

P5766

C0134

C0279

C0023

C0068

Cav

Col

CCT

1

YB

1

2

U

1

4

WB

1

CONNECTOR

C0070

DEFENDER 1999 MY

Motor - Headlamp levelling -
RH

Female
NATURAL

Behind RH headlamp

P5576

C0011

C0070

Cav

Col

CCT

1

UY

27

2

B

27

3

RO

27

C0071

CONNECTOR

DEFENDER 1999 MY

Motor - Headlamp levelling -
LH

Female
NATURAL

Behind LH headlamp

P5581

C0009

C0071

Cav

Col

CCT

1

UY

27

2

B

27

3

RO

27

CONNECTOR

C0074

DEFENDER 1999 MY

Cigar lighter illumination

Female
RED

Adjacent steering column

P5656

C1196

C1194

C0093

C0074

C1195

C0089

C1197

Cav

Col

CCT

1

RO

ALL
