   CONNECTOR DETAILS

DEFENDER 90 NAS

C425

C425
HEATSINK RESISTOR

Under LH side of dash

Cav

Color Cct

1

RB

ALL

2

RW

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C448

C448
MAIN HARNESS TO
ENGINE HARNESS
13 Way
Female
BLACK
RH side of fire wall

Cav

Color Cct

Cav

Color Cct

1

GU

ALL

8

BO

ALL

2

WS

ALL

9

BS

ALL

3

WN

ALL

10

BY

ALL

4

GN

ALL

11

RS

ALL

5

YK

ALL

12

NY

ALL

6

OB

ALL

13

G

ALL

7

YB

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

C449

C449
MAIN HARNESS TO
ENGINE HARNESS
14 Way
Female
GREY
RH side of fire wall

Cav

Color Cct

Cav

Color Cct

1

WLG

ALL

8

YR

ALL

2

WK

ALL

9

SB

ALL

3

B

ALL

10

BK

ALL

4

WG

ALL

11

GW

ALL

5

BR

ALL

12

SR

ALL

6

BU

ALL

13

GB

ALL

7

NO

ALL

14

PB

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C450

C450
MAIN HARNESS TO
ENGINE HARNESS
4 Way
Male
BLACK
RH side of fire wall

Cav

Color Cct

1

PW

ALL

2

WP

ALL

3

NLG

ALL

4

NR

ALL
