   CONNECTOR DETAILS

DEFENDER 90 NAS

C219

C219
NOT USED

Behind instrument pack

t:\compuset\erl\faceview\51100465.tif

Cav

Color Cct

1

SR

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C230

C230
INSTRUMENT PACK
10 Way
Female
NATURAL
Behind instrument pack

Cav

Color Cct

Cav

Color Cct

1

WB

ALL

6

WY

ALL

3

WN

ALL

8

PY

ALL

4

WG

ALL

9

GW

ALL

5

YN

ALL

10

GR

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

C231

C231
INSTRUMENT
HARNESS TO MAIN
HARNESS
10 Way
Male
LIGHT GREY
Behind instrument pack

Cav

Color Cct

Cav

Color Cct

1

WG

ALL

6

WS

ALL

2

B

ALL

7

GB

ALL

3

YK

ALL

8

GU

ALL

4

RW

ALL

9

WB

ALL

5

SR

ALL

10

BR

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C233

C233
INSTRUMENT PACK
10 Way
Female
NATURAL
Behind instrument pack

Cav

Color Cct

1

LGP

ALL

2

B

ALL

3

RO

ALL

5

UW

ALL

8

BU

ALL

9

WG

ALL

10

RS

ALL
