Jeep XJ. Manual - part 262

SENSOR

VEHICLE SPEED

CONTROL SERVO

VEHICLE SPEED

3

1

4

1

BLACK

VEHICLE SPEED SENSOR SIGNAL

G7 18WT/OR

3

SENSOR GROUND

K167 20BR/YL

2

5V SUPPLY

K7 18OR

1

FUNCTION

CIRCUIT

CAV

GROUND

Z1 18BK

4

SPEED CONTROL BRAKE SWITCH OUTPUT

V30 20DB/RD

3

SPEED CONTROL VENT SOLENOID CONTROL

V35 18LG/RD

2

SPEED CONTROL VACUUM SOLENOID CONTROL

V36 18TN/RD

1

FUNCTION

CIRCUIT

CAV

(DIESEL)

CAV

CIRCUIT

FUNCTION

1

Z1 20BK

GROUND

2

M1 20PK

FUSED B(+)

BLACK

1

2

CAV

CIRCUIT

FUNCTION

1

L60 20TN

RIGHT TURN SIGNAL

2

-

-

3

L62 20BR/RD

RIGHT TURN SIGNAL

4

L55 20RD/WT

COMBINATION FLASHER INPUT

5

L6 20RD/WT

FLASHER OUTPUT

6

L12 20VT/TN

HAZARD FLASHER SELECT SIGNAL

7

-

-

8

-

-

9

L63 20DG/RD

LEFT TURN SIGNAL

10

L61 20LG/WT

LEFT TURN SIGNAL

11

L55 20RD/WT

COMBINATION FLASHER INPUT

BLACK

6

1

11

7

TURN SIGNAL/

HAZARD SWITCH

UNDERHOOD

LAMP/

SWITCH

8W - 80 - 90

8W-80 CONNECTOR PIN-OUTS

XJ

J008W-7

XJI08090

SWITCH

FLUID LEVEL

WASHER

B

A

BLACK

LOW WASHER FLUID SENSE

G29 20BK/LB

B

GROUND

Z1 20BK

A

FUNCTION

CIRCUIT

CAV

1

2

BLACK

SENSOR GROUND

K167 20BR/YL

2

WATER IN FUEL SENSOR SIGNAL

G123 18DG/WT

1

FUNCTION

CIRCUIT

CAV

SENSOR

WATER IN FUEL

CAV

CIRCUIT

FUNCTION

A

V10 18BR

WASHER PUMP CONTROL

B

Z1 18BK

GROUND

BLACK

A

B

WINDSHIELD

WASHER PUMP

SWITCH

WIPE/WASH

1

6

NATURAL

WIPER HIGH SPEED OUTPUT

V4 16BR/VT

6

FUSED IGNITION SWITCH OUTPUT (RUN-ACC)

V6 16DB

5

WIPER LOW SPEED OUTPUT

V3 16BR/WT

4

WASHER PUMP CONTROL

V10 18BR

3

WIPER PARK SWITCH SENSE

V5 16DG/YL

2

GROUND

Z1 16BK

1

FUNCTION

CIRCUIT

CAV

(GAS)

SENSOR

VEHICLE SPEED

CAV

CIRCUIT

FUNCTION

1

K6 18VT/OR

5V SUPPLY

2

K167 20BR/YL

SENSOR GROUND

3

G7 18WT/OR

VEHICLE SPEED SENSOR SIGNAL

1

3

(DIESEL)

BLACK

XJ

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 91

XJI08091

J008W-7

8W-90 CONNECTOR LOCATIONS

DESCRIPTION AND OPERATION

INTRODUCTION

This section provides illustrations identifying com-

ponent and connector locations in the vehicle. A con-
nector index is provided. Use the wiring diagrams in

each section for connector number identification.
Refer to the index for the proper figure number.

CONNECTOR/GROUND LOCATIONS

For items that are not shown in this section N/S is

placed in the Fig. column.

Connector
Name/Number

Color

Location

Fig.

A/C
Compressor
Clutch (Diesel)

BK

Left Rear of
Engine
Compartment

41, 42

A/C-Heater
Control or
Heater Control -
C1

BK

Center of
Instrument
Panel

22, 23

A/C-Heater
Control - C2

NAT

Center of
Instrument
Panel

22, 23

A/C High
Pressure Switch
(2.5L)(LHD)

Near T/O for
C107

8

A/C High
Pressure Switch
(2.5L)(RHD)

Right Side of
Engine
Compartment
Near Power
Distribution
Center

7

A/C High
Pressure Switch
(4.0L)(LHD)

Right Side of
Engine
Compartment
Near Power
Distribution
Center

12, 14

A/C High
Pressure Switch
(4.0L)(RHD)

Left Side of
Engine
Compartment
Near T/O for
A/C
Compressor
Clutch

15

A/C High
Pressure Switch
(Diesel)

Left Side of
Engine

41, 42

A/C Low
Pressure Switch
(Diesel)(LHD)

Right Rear of
Engine
Compartment

39

Connector
Name/Number

Color

Location

Fig.

A/C Low
Pressure Switch
(Diesel)(RHD)

Left Rear of
Engine
Compartment

37

A/C Low
Pressure Switch
(Gas)(LHD)

Right Rear of
Engine
Compartment

4, 12

A/C Low
Pressure Switch
(Gas)(RHD)

Left Rear of
Engine
Compartment

3, 11

Accelerator
Pedal Position
Sensor (Diesel)
(LHD)

BK

Near T/O for
Engine Control
Module - C1,
C2

N/S

Accelerator
Pedal Position
Sensor
(Diesel)(RHD)

BK

Right Kick
Panel Area

40

Airbag Control
Module

YL

Under Center
Console

27, 32

Ambient
Temperature
Sensor

BK

Center Grill
Opening

4, 5,
12, 13,
39, 40

Back-Up Lamp
Switch (2.5L)

BK

Right Side of
Transmission
Near Shifter

19

Back-Up Lamp
Switch (4.0L)

BK

Left Side of
Transmission

20

Back-Up Lamp
Switch (Diesel)

BK

Left Side of
Transmission

43

Battery
Temperature
Sensor

BK

At Battery

6, 7,
12, 13,
14, 15,
38

Blend Door
Actuator

BK

T/O at T/O for
C209 on HVAC
Harness

N/S

Blower Motor

On HVAC
Harness

N/S

XJ

8W - 90 CONNECTOR LOCATIONS

8W - 90 - 1
