(16) Re-connect the repaired connector. tems. TERMINAL REPLACEMENT (1) Disconnect battery. its mating half. Remove connector locking wedge, if (3) Remove connector locking wedge, if required (Fig. 19). (4) Position the connector locking finger away from the terminal using the proper pick from special tool (5) Cut the wire 6 inches from the back of the con- nector. (6) Remove 1 inch of insulation from the wire on the harness side. (7) Select a wire from the terminal repair assem- bly that best matches the color wire being repaired. (8) Cut the repair wire to the proper length and remove 1 inch of insulation. (9) Place a piece of heat shrink tubing over one side of the wire. Make sure the tubing will be long (10) Spread the strands of the wire apart on each part of the exposed wires. (11) Push the two ends of wire together until the strands of wire are close to the insulation. (12) Twist the wires together. core type solder only. Do not use acid core solder. (14) Center the heat shrink tubing over the joint and heat using a heat gun. Heat the joint until the (15) Insert the repaired wire into the connector. the connector locking wedge, if required, and reconnect the connector to its mating (17) Re-tape the wire harness starting 1-1/2 inches behind the connector and 2 inches past the repair. (18) Connect battery, and test all affected systems. DIODE REPLACEMENT (1) Disconnect the battery. the protective covering. (3) Remove the diode from the harness, pay atten- tion to the current flow direction (Fig. 22). Fig. 19 Connector Locking Wedge Tab (Typical) 1 – CONNECTOR Fig. 20 Terminal Removal 1 – CONNECTOR Fig. 21 Terminal Removal Using Special Tool 1 – FROM SPECIAL TOOL KIT 6680 8W - 01 - 14 8W - 01 GENERAL INFORMATION XJ SERVICE PROCEDURES (Continued) |
