Towing Tips
Before setting out on a trip, practice turning, stopping
and backing the trailer in an area away from heavy
traffic.
Towing Tips — Automatic Transmission
The “D” range can be selected when towing. However,
if frequent shifting occurs while in this range, the “3”
range should be selected.Using the “3” range while
operating the vehicle under heavy operating conditions
will improve performance and extend transmission life
by reducing excessive shifting and heat build up. This
action will also provide better engine braking.
The automatic transmission fluid and filter should be changed if you REGULARLY tow a trailer for more than 45
minutes of continuous operation. See Schedule “B” in section 8 of this manual for transmission fluid change inter-
vals.
NOTE: Check the automatic transmission fluid level before towing.
Towing Tips — Electronic Speed Control (If Equipped)
− Don’t use in hilly terrain or with heavy loads.
− When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until
you can get back to cruising speed.
− Use speed control in flat terrain and with light loads to maximize fuel efficiency.
Towing Tips — Autostick (If Equipped)
− For vehicles equipped with Autostick. By using the Autostick modes, and selecting a specific gear range, fre-
quent shifting can be avoided. The highest gear range should be selected that allows for adequate performance.
For example, choose “4” if the desired speed can be maintained. Choose “3” or “2” if needed to maintain the
desired speed.
− Extended driving at high RPM should be avoided to prevent excess heat generation. A reduction in vehicle
speed may be required to avoid extended driving at high RPM. Return to a higher gear range or vehicle speed
when road conditions and RPM level allows.
Towing Tips — Cooling System
To reduce potential for engine and transmission overheating, take the following actions:
•
City Driving - When stopped for short periods of time, put transmission in neutral and increase engine idle
speed.
•
Highway Driving - Reduce speed.
•
Air Conditioning - Turn off temporarily.
•
refer to Cooling System Operating information in the Maintenance section of this manual for more information.
