Jeep Liberty KJ. Manual - part 134
VANITY LAMP
REMOVAL - BULB
NOTE: Vehicles equipped with optional vanity lamps have a mirror with a lamp that is integral to each sun
visor. Each lamp is independently controlled by an integral switch that is automatically actuated by the mir-
ror cover. The bulb types and service procedures are identical for both of these lamps.
1. Disconnect and isolate the battery negative cable.
2. Insert a small thin-bladed tool on either side of the
mirror (2) near the top or the bottom between the
vanity lamp lens (1) and the sun visor (3) vanity
lamp housing.
3. Carefully pry the lens outward until it unsnaps from
the lamp housing.
4. Using small needle-nose pliers (4), carefully grasp
the bulb (5) and pull the base out of the lamp
socket (3).
INSTALLATION - BULB
CAUTION: Always use the correct bulb size and type for replacement. An incorrect bulb size or type may
overheat and cause damage to the lamp, the socket and/or the lamp wiring.
NOTE: Vehicles equipped with optional vanity lamps have a mirror with a lamp that is integral to each sun
visor. Each lamp is independently controlled by an integral switch that is automatically actuated by the mir-
ror cover. The bulb types and service procedures are identical for both of these lamps.
8L - 194
LAMPS/LIGHTING - INTERIOR
KJ
