B1B70-UP-FRONT LEFT SATELLITE ACCELERATION SENSOR INTERNAL (CONTINUED) 4. CHECK THE (R79, R81) FRONT LEFT IMPACT SENSOR CIRCUITS FOR A SHORT TOGETHER Measure the resistance between the (R79) Front Left Impact Sensor Is the resistance below 100K ohms? Yes >> Repair the (R79, R81) Front Left Impact Sensor circuits shorted together. Perform the ORC VERIFICATION TEST - VER 1. No >> Go To 5 5. CHECK THE (R81) FRONT LEFT IMPACT SENSOR GROUND CIRCUIT FOR AN OPEN OR HIGH Connect the 8443 Load Tool ORC Adaptor to the Occupant Restraint Measure the resistance of the (R81) Front Left Impact Sensor Ground Is the resistance below 1 ohm? Yes >> Go To 6 No >> Repair the (R81) Front Left Impact Sensor 1 Ground cir- cuit for an open or high resistance. Perform the ORC VERIFICATION TEST - VER 1. 8O - 162 RESTRAINTS - ELECTRICAL DIAGNOSTICS WK |
