Jeep Grand Cherokee WK. Manual - part 1149





Connecting Rod Guides 8507

Crankshaft Damper Installer 8512

Puller 1026

Crankshaft Damper Removal Insert 8513 - A

Chain Tensioner

Chain Tensioner Pins 8514

VALVE SPRING COMPRESSOR 8426

ENGINE LIFTING FIXTURE 8427

9 - 1192

ENGINE - 3.7L SERVICE INFORMATION

WK

CAMSHAFT HOLDER 8428

HOLDER SECONDARY CAMSHAFT CHAIN 8429

Remover, Rocker Arm 8516

Idler Shaft Remover 8517

Valve Spring Compressor Adapters 8519

INSTALLER COUNTER BALANCE SHAFT 8641

Valve Spring Tester C-647

WK

ENGINE - 3.7L SERVICE INFORMATION

9 - 1193

Dial Indicator C-3339

Valve Spring Compressor C-3422-B

Indicator, Cylinder Bore C-119

Oil Pressure Gauge C-3292

Piston Ring Compressor C-385

Pressure Tester Kit 7700

Bloc–Chek–Kit C-3685–A

ENGINE SUPPORT FIXTURE 8534

9 - 1194

ENGINE - 3.7L SERVICE INFORMATION

WK

CLEANER-AIR ELEMENT

REMOVAL

Filter Element Only

Housing removal is not necessary for element (filter)
replacement.

1. Loosen clamp (1) and disconnect air duct at air

cleaner cover (3).

2. Pry over 4 spring clips (5) from housing cover

(spring clips retain cover to housing).

3. Release housing cover (3) from locating tabs on

housing and remove cover (3).

4. Remove air cleaner element (filter) from housing.

5. Clean inside of housing before replacing element.

Housing Assembly

1. Loosen clamp and disconnect air duct at air

cleaner cover.

2. Lift entire housing assembly (1) from 4 locating

pins (2).

WK

ENGINE - 3.7L SERVICE INFORMATION

9 - 1195
