8W-90 CONNECTOR LOCATIONS

DESCRIPTION AND OPERATION

INTRODUCTION

This section provides illustrations identifying com-

ponent and connector locations in the vehicle. A con-
nector index is provided. Use the wiring diagrams in

each section for connector number identification.
Refer to the index for the proper figure number.

CONNECTOR/GROUND LOCATIONS

For items that are not shown in this section N/S is

placed in the Fig. column.

Connector
Name/Number

Color

Location

Fig.

A/C Compressor
Clutch

BK

At A/C
Compressor

6,
12

A/C High
Pressure Switch

BK

Near Radiator
Fan Motor

4

A/C Low
Pressure Switch

GY

Right Rear of
Engine
Compartment

4

Accelerator Pedal
Position Sensor
(Diesel)

BK

Rear of Engine
Compartment
Near Fuel/Water
Seperator

19

Airbag Control
Module

YL

Below Center
Floor Console,
Near Park Brake

20,
21,
22,
23

Ambient
Temperature
Sensor

BK

On Radiator
Center Support

1, 4

Antenna Module

WT

Above Right
Quarter Window

38

Ash Receiver
Lamp

BK

Below Cigarette
Lighter

20,
21

Automatic
Day/Night Mirror

BK

In Front of Rear
View Mirror

N/S

Automatic
Headlamp Light
Sensor/VTSS
LED

BK

Near Left
Instrument
Panel Speaker

20,
21

Automatic Zone
Control Module -
C1

BK

Left Side of
HVAC Housing

20,
21

Automatic Zone
Control Module -
C2

BK

Left Side of
HVAC Housing

20,
21

Battery
Temperature
Sensor

BK

Below Battery
Tray

4

Connector
Name/Number

Color

Location

Fig.

Blower Motor

BK

Behind Right
Hand Side of
Instrument
Panel

N/S

Blower Motor
Controller (AZC)

BK

Behind Right
Hand Side of
Instrument
Panel

N/S

Blower Motor
Resistor Block
(MTC)

BK

Behind Right
Hand Side of
Instrument
Panel

N/S

Body Control
Module - C1

GY

Lower Left Side
of Instrument
Panel

22,
23

Body Control
Module-C2 -LHD

WT

Lower Left Side
of Instrument
Panel

22,
23

Body Control
Module-C2 - RHD

GY

Lower Left Side
of Instrument
Panel

22,
23

Brake Lamp
Switch

GY

Brake Pedal
Arm

N/S

Brake Shift
Interlock Solenoid

WT

Bottom of
Steering Column

24

Brake Warning
Indicator Switch

GY

At Master
Cylinder

N/S

C100

BK

Right Front
Engine
Compartment

2, 4

C102

BK

Right Rear
Engine
Compartment

2, 4,
6, 9,
10,
13,
14,
17
