LAN TROUBLE DIAGNOSIS LAN-11 < FUNCTION DIAGNOSIS > [CAN FUNDAMENTAL] C D E F G H I J K L B A O P N Self-Diagnosis INFOID:0000000005152908 CAN Diagnostic Support Monitor INFOID:0000000005146447 CONSULT-III and CAN diagnostic support monitor (on-board diagnosis function) are used for detecting root cause. MONITOR ITEM (CONSULT-III) Example: CAN DIAG SUPPORT MNTR indication Without PAST DTC Self-diagnosis item (CONSULT-III indication) DTC detection condition Inspection/Action U0101 LOST COMM (TCM) When ECM is not transmitting or receiving CAN commu- Start the inspection. Refer U0140 LOST COMM (BCM) When ECM is not transmitting or receiving CAN commu- U0164 LOST COMM (HVAC) When ECM is not transmitting or receiving CAN commu- U1000 CAN COMM CIRCUIT ECM When ECM is not transmitting or receiving Except When a control unit (except for ECM) is not U1001 CAN COMM CIRCUIT When ECM is not transmitting or receiving CAN commu- U1002 SYSTEM COMM When a control unit is not transmitting or receiving CAN U1010 CONTROL UNIT(CAN) When an error is detected during the initial diagnosis for Replace the control unit P0607 ECM PKID1075E |
