GI-34 < BASIC INSPECTION > SERVICE INFORMATION FOR ELECTRICAL INCIDENT BASIC INSPECTION SERVICE INFORMATION FOR ELECTRICAL INCIDENT Work Flow INFOID:0000000005149604 WORK FLOW Control Units and Electrical Parts INFOID:0000000005149605 PRECAUTIONS • Never reverse polarity of battery terminals. • Install only parts specified for a vehicle. • Before replacing the control unit, check the input and output and functions of the component parts. • Do not apply excessive force when disconnecting a connector. SGI838 STEP DESCRIPTION STEP 1 Get detailed information about the conditions and the environment when the incident occurred. WHAT Vehicle Model, Engine, Transmission/Transaxle and the System (i.e. Radio). WHEN Date, Time of Day, Weather Conditions, Frequency. WHERE Road Conditions, Altitude and Traffic Situation. HOW System Symptoms, Operating Conditions (Other Components Interaction). STEP 2 Operate the system, road test if necessary. STEP 3 Get the proper diagnosis materials together including: STEP 4 Inspect the system for mechanical binding, loose connectors or wiring damage. STEP 5 Repair or replace the incident circuit or component. STEP 6 Operate the system in all modes. Verify the system works properly under all conditions. Make sure you have not inad- |
