BCM (BODY CONTROL MODULE) EXL-113 < ECU DIAGNOSIS > C D E F G H I J K M A B EXL N O P 44 O Rear wiper auto stop Input ON Rise up position (rear wiper 0V A Position (full clockwise stop Battery voltage Forward sweep (counterclock- Fluctuating B Position (full counterclock- 0V Reverse sweep (clockwise di- Fluctuating 47 SB Front door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 48 R/Y Rear door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 49 R Cargo lamp Output OFF Any door open (ON) 0V All doors closed (OFF) Battery voltage 51 G/Y Trailer turn signal Output ON Turn right ON 52 G/B Trailer turn signal (left) Output ON Turn left ON 53 L/W Glass hatch lock actu- Output OFF Glass hatch switch released 0V Glass hatch switch pressed Battery voltage 54 Y Rear wiper output cir- Input ON Rise up position (rear wiper 0V A Position (full clockwise stop 0V Forward sweep (counterclock- 0V B Position (full counterclock- Battery voltage Reverse sweep (clockwise di- Battery voltage 55 SB Rear wiper output cir- Output ON OFF 0V ON Battery voltage 56 R/G Battery saver output Output OFF 30 minutes after ignition 0V ON — Battery voltage 57 Y/R Battery power supply Input OFF — Battery voltage Terminal Wire color Signal name Signal input/ output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition SKIA3009J SKIA3009J |
