FRONT OIL SEAL DLN-211 < ON-VEHICLE REPAIR > [FRONT FINAL DRIVE: M205] C E F G H I J K L M A B DLN N O P FRONT OIL SEAL Removal and Installation INFOID:0000000005148919 REMOVAL 1. Remove the drive shafts from the front final drive assembly. Refer to FAX-9, "Removal and Installation" 2. Remove the front propeller shaft from the front final drive assembly. Refer to . 3. Measure the total preload torque. Refer to DLN-234, "General Specification" NOTE: Record the total preload torque measurement. 4. Remove the drive pinion lock nut using suitable tool. 5. Put matching marks on the companion flange and drive pinion using paint. CAUTION: Use paint to make the matching marks. Do not damage the companion flange or drive pinion. 6. Remove companion flange using suitable tool. 7. Place a small hole in the front oil seal case using suitable tool. BDIA0001E LDIA0171E LDIA0129E |
