PRECAUTIONS HA-5 < PRECAUTION > C D E F G H J K L M A B HA N O P - Never allow lubricant (A/C System Oil Type R) to come in contact with styrene foam parts. Damage may result. REFRIGERANT CONNECTION A new type refrigerant connection has been introduced to all refrigerant lines except the following location. WARNING: Check that all refrigerant is discharged into the recycling equipment and the pressure in the system is CAUTION: Observe the following when replacing or cleaning refrigerant cycle components. to do so will cause lubricant to enter the low-pressure chamber. • Use always a torque wrench and a back-up wrench when connecting tubes. Never remove the seal caps of pipes and other components until just before required for connection. • Allow components stored in cool areas to warm to working area temperature before removing seal caps. This prevents condensation from forming inside A/C components. • Remove thoroughly moisture from the refrigeration system before charging the refrigerant. apply lubricant to threaded portion. • O-ring must be closely attached to the groove portion of tube. installed to tube correctly. • Perform leakage test and make sure that there is no leakage from connections after connecting line. Disconnect that line and replace the O-ring when the refrigerant leaking point is found. Then tighten COMPRESSOR CAUTION: • Plug all openings to prevent moisture and foreign matter from entering. ing compressor. Refer to • Keep friction surfaces between clutch and pulley clean. Wipe it off by using a clean waste cloth moistened with thinner if the surface is contaminated with lubricant. Name A/C System Oil Type S RHA861F |
