BCS-66

< WIRING DIAGRAM >

BCM

JCMWM8299GB

BCS

INSPECTION AND ADJUSTMENT

BCS-67

< BASIC INSPECTION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

BASIC INSPECTION

INSPECTION AND ADJUSTMENT

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (BCM)

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (BCM) : Description

INFOID:0000000006324908

BEFORE REPLACEMENT

When replacing BCM, save or print current vehicle specification with CONSULT-III configuration before
replacement.
NOTE:
If “READ CONFIGURATION” can not be used, use the “WRITE CONFIGURATION - Manual selection” after
replacing BCM.

AFTER REPLACEMENT

CAUTION:

• When replacing BCM, you must perform “WRITE CONFIGURATION” with CONSULT-III.
- Complete the procedure of “WRITE CONFIGURATION” in order.
- If you set incorrect “WRITE CONFIGURATION”, incidents might occur.
- Configuration is different for each vehicle model. Confirm configuration of each vehicle model.
• When replacing BCM, perform the system initialization (NATS).

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (BCM) : Work Proce-
dure

INFOID:0000000006324909

1.

SAVING VEHICLE SPECIFICATION

CONSULT-III Configuration

Perform “READ CONFIGURATION” to save or print current vehicle specification. Refer to

BCS-67, "CONFIG-

URATION (BCM) : Description"

.

NOTE:
If “READ CONFIGURATION” can not be used, use the “WRITE CONFIGURATION - Manual selection” after
replacing BCM.

>> GO TO 2.

2.

REPLACE BCM

Replace BCM. Refer to

BCS-81, "Removal and Installation"

.

>> GO TO 3.

3.

WRITING VEHICLE SPECIFICATION

CONSULT-III Configuration

Perform “WRITE CONFIGURATION - Config file” or “WRITE CONFIGURATION - Manual selection” to write
vehicle specification. Refer to

BCS-68, "CONFIGURATION (BCM) : Work Procedure"

.

>> GO TO 4.

4.

INITIALIZE BCM (NATS)

Perform BCM initialization. (NATS)

>> WORK END

CONFIGURATION (BCM)

CONFIGURATION (BCM) : Description

INFOID:0000000006324910

Vehicle specification needs to be written with CONSULT-III because it is not written after replacing BCM.

BCS-68

< BASIC INSPECTION >

INSPECTION AND ADJUSTMENT

Configuration has three functions as follows.

NOTE:

Manual setting item: Items which need selection by vehicle specifications

Automatic setting item: Items which are written in automatically (Setting can not be changed)

CAUTION:

• When replacing BCM, you must perform “WRITE CONFIGURATION” with CONSULT-III.
• Complete the procedure of “WRITE CONFIGURATION” in order.
• If you set incorrect “WRITE CONFIGURATION”, incidents might occur.
• Configuration is different for each vehicle model. Confirm configuration of each vehicle model.
• Never perform “WRITE CONFIGURATION” except for new BCM.

CONFIGURATION (BCM) : Work Procedure

INFOID:0000000006324911

1.

WRITING MODE SELECTION

CONSULT-III Configuration

Select “CONFIGURATION” of BCM.

When writing saved data>>GO TO 2.
When writing manually>>GO TO 3.

2.

PERFORM “WRITE CONFIGURATION - CONFIG FILE”

CONSULT-III Configuration

Perform “WRITE CONFIGURATION - Config file”.

>> WORK END

3.

PERFORM “WRITE CONFIGURATION - MANUAL SELECTION”

CONSULT-III Configuration

1.

Select "WRITE CONFIGURATION - Manual selection".

2.

Identify the correct model and configuration list. Refer to

BCS-69, "CONFIGURATION (BCM) : Configura-

tion list"

.

3.

Confirm and/or change setting value for each item.

CAUTION:

• Thoroughly read and understand the vehicle specification. Incorrect settings may result in

abnormal control of ECU.

• If items are not displayed, touch “SETTING”. Refer to

BCS-69, "CONFIGURATION (BCM) : Con-

figuration list"

  for written items and setting value.

4.

Select "SETTING".

CAUTION:

Make sure to select “SETTING” even if the indicated configuration of brand new BCM is same as
the desirable configuration. If not, configuration which is set automatically by selecting vehicle
model can not be memorized.

5.

When "COMMAND FINISHED", select "END".

>> GO TO 4.

4.

OPERATION CHECK

Confirm that each function controlled by BCM operates normally.

>> WORK END

Function

Description

READ CONFIGURATION

• Reads the vehicle configuration of current BCM.
• Saves the read vehicle configuration.

WRITE CONFIGURATION - Manual selection

Writes the vehicle configuration with manual selection.

WRITE CONFIGURATION - Config file

Writes the vehicle configuration with saved data.

BCS

INSPECTION AND ADJUSTMENT

BCS-69

< BASIC INSPECTION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

CONFIGURATION (BCM) : Configuration list

INFOID:0000000006274828

Items and setting value that are written in BCM by the write configuration can be checked by “READ CONFIG-
URATION” as shown in the following table.

SETTING ITEM

NOTE

Items

Setting value

HZRD (SHCK DTCT ULK) FUNC

WITH

—

UNLOCK WITH SHOCK

WITHOUT

—

CAN CONNECTION UNIT

MODE1

—

NISSAN/INFINITI SETTING

INFINITI

—

AUTO LIGHT

WITH

—

RAIN SENSOR CONFIG

WITH

—

THEFT ALM AREA

MODE2

—

AT DOOR LK VHCL SPED SET

MODE2

—

TPMS

TPMS SBF

—
