System Description
NBHA0110
SWITCHES AND THEIR CONTROL FUNCTIONS
NBHA0110S01
RHA044GA
Position
or switch
MODE SW
DEF SW
AUTO
SW
ECON
SW
REC SW
Temperature SW
VENT
B/L
FOOT
D/F
ON
OFF
ON
OFF
Door
18.0°C
(65°F)
—
32.0°C
(85°F)
Ventila-
tor door
A
B
C
C
C
—
AUTO
AUTO
—
—
Foot
door
A
B
C
C
A
—
—
Defroster
door
A
A
B
C
C
—
—
Air mix
door
—
—
—
A
AUTO
B
Intake
door
—
C
A
AUTO*1
—
*1: Automatically controlled when REC switch is OFF.
