CAN COMMUNICATION
LAN-41
[CAN]
C
D
E
F
G
H
I
J
L
M
A
B
LAN
TYPE 1
System Diagram
Input/output Signal Chart
T: Transmit R: Receive
PKIA9780E
Signals
ECM
TCM
VDC/TCS/
ABS con-
trol unit
Pre-crash
seat belt
control unit
Steering
angle sen-
sor
Combina-
tion meter
Accelerator pedal position signal
T
R
R
ASCD CRUISE lamp signal
T
R
ASCD SET lamp signal
T
R
Battery voltage signal
T
R
Closed throttle position signal
T
R
Engine coolant temperature signal
T
R
Engine speed signal
T
R
R
R
Fuel consumption monitor signal
T
R
Malfunction indicator lamp signal
T
R
Wide open throttle position signal
T
R
A/T self-diagnosis signal
R
T
A/T CHECK indicator lamp signal
T
R
A/T position indicator lamp signal
T
R*
R
Current gear position signal
R
T
R
Manual mode indicator signal
T
R
Next gear position signal
R
T
R
Output shaft revolution signal
R
T
Shift change signal
R
T
R
Shift pattern signal
R
T
Turbine revolution signal
R
T
ABS operation signal
R
T
ABS warning lamp signal
T
R
SLIP indicator lamp signal
T
R
VDC OFF indicator lamp signal
T
R
Vehicle speed signal
T
R
R
R
R
T
