DTC P1762 DIRECT CLUTCH SOLENOID VALVE AT-149 D E F G H I J K L M A B AT DTC P1762 DIRECT CLUTCH SOLENOID VALVE PFP:31940 Description NCS000Y8 Direct clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle CONSULT-II Reference Value NCS000Y9 On Board Diagnosis Logic NCS000YA ● This is an OBD-II self-diagnostic item. ● Diagnostic trouble code “P1762 D/C SOLENOID/CIRC” with CONSULT-II or 2nd judgement flicker without – When TCM detects an improper voltage drop when it tries to operate the solenoid valve. – When TCM detects as irregular by comparing target value with monitor value. Possible Cause NCS000YB ● Harness or connectors ● Direct clutch solenoid valve DTC Confirmation Procedure NCS000YC CAUTION: Always drive vehicle at a safe speed. WITH CONSULT-II 1. Turn ignition switch ON. (Do not start engine.) 2. Select “SELECTION FROM MENU” in “DATA MONITOR” mode 3. Touch “START”. 4. Start engine. 5. Drive vehicle and maintain the following conditions for at least 5 Þ “2” (D/C ON/OFF) Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving 6. AT-150, "Diagnostic Procedure" WITH GST Follow the procedure “WITH CONSULT-II”. Item name Condition Display value (Approx.) D/C SOLENOID Direct clutch disengaged. Refer to 0.6 - 0.8 A Direct clutch engaged. Refer to 0 - 0.05 A BCIA0031E |
