SFA234AC 4. Measure distance “A” (rear side). 5. Push the vehicle slowly ahead to rotate the wheels 180 If the wheels have rotated more than 180 degrees (1/2 turn), try Measure distance “B” (front side). Total toe-in: Refer to SDS (FA-60). SMA727A 7. Adjust toe-in by varying the length of steering tie-rods. a. Loosen lock nuts. SFA486A b. Adjust toe-in by screwing tie-rods in and out. Standard length “L”: Refer to SDS in ST section. c. Tighten lock nuts to specified torque. Lock nut tightening torque: Refer to POWER STEERING GEAR AND LINKAGE SFA439BA FRONT WHEEL TURNING ANGLE 1. Set wheels in straight-ahead position. Then, move vehicle for- 2. Rotate steering wheel all the way right and left; measure turn- Wheel turning angle (Full turn): Refer to SDS (FA-60). GI MA EM LC EC FE AT PD RA BR ST RS BT HA EL IDX ON-VEHICLE SERVICE Front Wheel Alignment (Cont’d) FA-11 |
