SEL548W

DIAGNOSTIC PROCEDURE 12
(Reclining motor check)

SEL975U

SEL976U

RECLINING MOTOR ACTIVE TEST

CONSULT-II

See “SEAT RECLINING” in ACTIVE TEST
mode.
Perform operation shown on display.
Reclining motor should operate.
Note: If CONSULT-II is not available,

start with diagnostic procedure

.

NG

E

OK

Reclining motor is OK.

CHECK OUTPUT SIGNAL TO RECLIN-
ING MOTOR.
Check voltage between LCU05 connector
terminals

q

2

or

q

9

and ground.

Refer to wiring diagram in EL-452.

OK

E

NG

Replace LCU05.

CHECK RECLINING MOTOR.
1. Disconnect reclining motor connector.
2. Apply 12V DC direct current to motor

and check operation.

OK

E

NG

Replace reclining motor.

Check harness for operation between
LCU05 and reclining motor.

Condition

of reclin-

ing switch

Terminals

Voltage

V

!

@

Forward

q

2

Ground

Approx.

12

Backward

q

9

Ground

Approx.

12

Terminals

Operation

!

@

q

2

q

9

Forward

q

9

q

2

Backward

GI

MA

EM

LC

EC

FE

AT

PD

FA

RA

BR

ST

RS

BT

HA

IDX

AUTOMATIC DRIVE POSITIONER — IVMS

Trouble Diagnoses (Cont’d)

H

H

H

EL-475

SEL549W

DIAGNOSTIC PROCEDURE 13
[Lifting motor (Front) check]

SEL978U

SEL979U

LIFTING MOTOR (FRONT) ACTIVE
TEST

CONSULT-II

See “SEAT LIFTER FR” in ACTIVE TEST
mode.
Perform operation shown on display.
Lifting motor (front) should operate.
Note: If CONSULT-II is not available,

start with diagnostic procedure

.

NG

E

OK

Lifting motor (front) is OK.

CHECK OUTPUT SIGNAL TO LIFTING
MOTOR (FRONT).
Check voltage between LCU05 connector
terminals

q

11

or

q

10

and ground.

Refer to wiring diagram in EL-452.

OK

E

NG

Replace LCU05.

CHECK LIFTING MOTOR (FRONT).
1. Disconnect lifting device connector.
2. Apply 12V DC direct current to motor

and check operation.

OK

E

NG

Replace lifting motor
(front).

Check harness for operation between
LCU05 and lifting motor (front).

Condition

of lifting

switch

(front)

Terminals

Voltage

V

!

@

Up

q

11

Ground

Approx.

12

Down

q

10

Ground

Approx.

12

Terminals

Operation

!

@

q

11

q

10

Up

q

10

q

11

Down

AUTOMATIC DRIVE POSITIONER — IVMS

Trouble Diagnoses (Cont’d)

H

H

H

EL-476

SEL550W

DIAGNOSTIC PROCEDURE 14
[Lifting motor (Rear) check]

SEL002V

SEL003V

LIFTING MOTOR (REAR) ACTIVE TEST

CONSULT-II

See “SEAT LIFTER RR” in ACTIVE TEST
mode.
Perform operation shown on display.
Lifting motor (rear) should operate.
Note: If CONSULT-II is not available,

start with diagnostic procedure

.

NG

E

OK

Lifting motor (rear) is OK.

CHECK OUTPUT SIGNAL TO LIFTING
MOTOR (REAR).
Check voltage between LCU05 connector
terminals

q

6

or

q

4

and ground.

Refer to wiring diagram in EL-453.

OK

E

NG

Replace LCU05.

CHECK LIFTING MOTOR (REAR).
1. Disconnect lifting device connector.
2. Apply 12V DC direct current to motor

and check operation.

OK

E

NG

Replace lifting motor (rear).

Check harness for operation between
LCU05 and lifting motor (rear).

Condition

of lifting

switch

(rear)

Terminals

Voltage

V

!

@

Up

q

6

Ground

Approx.

12

Down

q

4

Ground

Approx.

12

Terminals

Operation

!

@

q

6

q

4

Up

q

4

q

6

Down

GI

MA

EM

LC

EC

FE

AT

PD

FA

RA

BR

ST

RS

BT

HA

IDX

AUTOMATIC DRIVE POSITIONER — IVMS

Trouble Diagnoses (Cont’d)

H

H

H

EL-477

SEL004V

DIAGNOSTIC PROCEDURE 15
(Lifting limit switch check)

SEL005V

CHECK LIMIT SWITCH.
1. Disconnect lifting device connector.
2. Check continuity between lifting device

(limit switch) terminals.

Refer to wiring diagram in EL-452 or 453.

OK

E

NG

Replace limit switch.

CHECK GROUND CIRCUIT FOR LIMIT
SWITCH.
Check continuity between lifting device
terminal

q

14

(for limit switch front) or

q

15

(for

limit switch rear) and ground.
Continuity should exist.

OK

E

NG

Repair harness.

Check harness for open or short between
LCU05 and limit switch.

Terminals

Condition of

seat lifting

Continuity

Front

q

12

-

q

14

Fully up

No

Except the

above

Yes

q

3

-

q

14

Fully down

No

Except the

above

Yes

Rear

q

5

-

q

15

Fully up

No

Except the

above

Yes

q

13

-

q

15

Fully down

No

Except the

above

Yes

AUTOMATIC DRIVE POSITIONER — IVMS

Trouble Diagnoses (Cont’d)

H

H

EL-478
