Infiniti Q45 (FY33). Manual - part 270





SEL852W

DIAGNOSTIC PROCEDURE 1

[Lighting switch (AUTO) check]

CHECK LIGHTING SWITCH (AUTO)
INPUT SIGNAL.

CONSULT-II

See “AUTO LIGHT SW” in DATA MONI-
TOR mode.
When lighting switch is in AUTO:

AUTO LIGHT SW

ON

When lighting switch is OFF:

AUTO LIGHT SW

OFF

-------------------------------------------------------------------------------------------------------------------------------------- OR --------------------------------------------------------------------------------------------------------------------------------------

ON BOARD

Perform On board diagnosis — Mode II
(Switch monitor) for light switch. Refer to
EL-299.

Refer to wiring diagram in EL-65.

OK

E

NG

Check the following.

I

Lighting switch

I

Harness for open or
short between BCM and
lighting switch

I

Ground circuit for lighting
switch

Lighting switch (AUTO) is OK.

SEL574W

DIAGNOSTIC PROCEDURE 2

(Auto light output check)

SEL098V

CHECK AUTO LIGHT OUTPUT SIGNAL/
CIRCUIT.

CONSULT-II

See “HEADLAMP RELAY” and “TAIL
LAMP RELAY” in ACTIVE TEST mode,
and turn lighting switch to AUTO position.
Headlamp and tail lamp should turn on.

-------------------------------------------------------------------------------------------------------------------------------------- OR --------------------------------------------------------------------------------------------------------------------------------------

TESTER

1. Turn the ignition switch to ON position

or lighting switch to AUTO position.

2. Check voltage between BCM terminal

q

5

or

q

11

and ground.

Refer to wiring diagram in EL-66.

OK

E

NG

Check harness for open or
short between BCM and
headlamp relay or tail lamp
relay.

Auto light output is OK.

Output condition

Voltage V

Sensor not struck by light

(Determined to be “dark” by

sensor)

0

Sensor struck by light

Approx. 12

GI

MA

EM

LC

EC

FE

AT

PD

FA

RA

BR

ST

RS

BT

HA

IDX

HEADLAMP (FOR U.S.A.) — CONVENTIONAL TYPE —

Trouble Diagnoses/Auto Light Operation
(Cont’d)

H

H

EL-71

SEL572W

DIAGNOSTIC PROCEDURE 3

(Optical sensor check)

SEL559UA

SEL853W

SEL017V

CHECK OPTICAL SENSOR INPUT SIG-
NAL.

CONSULT-II

See “OPTICAL SEN” in DATA MONITOR
mode.
When optical sensor is struck by light:

More than 3V

When optical sensor is not struck by light:

Approx. 0.5V

-------------------------------------------------------------------------------------------------------------------------------------- OR --------------------------------------------------------------------------------------------------------------------------------------

TESTER

1. Turn the ignition switch to ACC position.
2. Check voltage between BCM terminal

q

52

and ground.

Refer to wiring diagram in EL-67.

NG

E

OK

Optical sensor is OK.

CHECK OPTICAL SENSOR OPEN CIR-
CUIT.
1. Disconnect BCM connector and optical

sensor connector.

2. Check harness continuity between BCM

connector and optical sensor connector.

OK

E

NG

Repair harness.

CHECK OPTICAL SENSOR SHORT CIR-
CUIT.
Check harness continuity between BCM
connector and body ground.

OK

E

NG

Repair harness.

Replace optical sensor.

Condition of optical sensor

Voltage V

Sensor struck by light

More than 3

Sensor not struck by light

Approx. 0.5

Terminals

Continuity

BCM

Optical

sensor

q

58

q

3

Yes

q

52

q

2

q

59

q

1

Terminals

Continuity

q

58

- ground

No

q

52

- ground

q

59

- ground

HEADLAMP (FOR U.S.A.) — CONVENTIONAL TYPE —

Trouble Diagnoses/Auto Light Operation
(Cont’d)

H

H

H

EL-72

SEL499W

SEL855W

DIAGNOSTIC PROCEDURE 4

(IGN input signal check)

CHECK ACC AND IGN INPUT SIGNAL.

CONSULT-II

See “IGN ON SW” in DATA MONITOR
mode.
When ignition switch is ON:

IGN ON SW

ON

When ignition switch is OFF:

IGN ON SW

OFF

-------------------------------------------------------------------------------------------------------------------------------------- OR --------------------------------------------------------------------------------------------------------------------------------------

TESTER

Check voltage between BCM terminal

q

68

and ground.

Refer to wiring diagram in EL-67.

OK

E

NG

Check the following.

I

7.5A fuse [No.

32

,

located in the fuse block
(J/B)]

I

Harness for open or
short between fuse and
BCM

IGN input signal is OK.

Termi-

nals

Ignition switch position

OFF

ACC

ON

START

q

68

-

Ground

Approx. 0V

Battery voltage

GI

MA

EM

LC

EC

FE

AT

PD

FA

RA

BR

ST

RS

BT

HA

IDX

HEADLAMP (FOR U.S.A.) — CONVENTIONAL TYPE —

Trouble Diagnoses/Auto Light Operation
(Cont’d)

H

EL-73

SEL573W

DIAGNOSTIC PROCEDURE 5

(Illumination time control switch check)

SEL019V

SEL020V

CHECK ILLUMINATION TIME CONTROL
SWITCH INPUT SIGNAL.

CONSULT-II

See “ILLUM TIME” in DATA MONITOR
mode.
When time control switch is fully turned to
short time

Approx. 0 k

When time control switch is fully turned to
long time

Approx. 1 k

-------------------------------------------------------------------------------------------------------------------------------------- OR --------------------------------------------------------------------------------------------------------------------------------------

TESTER

1. Disconnect BCM connector.
2. Check resistance between BCM termi-

nal

q

57

and ground.

Refer to wiring diagram in EL-67.

NG

E

OK

Illumination time control
switch is OK.

CHECK ILLUMINATION TIME CONTROL
SWITCH.
1. Disconnect illumination time control

switch.

2. Check resistance between illumination

time control switch terminals

q

1

and

q

3

.

OK

E

NG

Replace illumination time
control switch.

Check the following:

I

Illumination time control switch ground
circuit

I

Harness for open or short between BCM
and illumination time control switch

Time control switch

condition

Resistance

k

Fully short

Approx. 0

Fully long

Approx. 1

Time control switch

condition

Resistance

k

Fully short

Approx. 0

Fully long

Approx. 1

HEADLAMP (FOR U.S.A.) — CONVENTIONAL TYPE —

Trouble Diagnoses/Auto Light Operation
(Cont’d)

H

H

EL-74
