MAIN 12 CAUSES OF OVERHEATING
Engine
Step
Inspection item
Equipment
Standard
Reference page
OFF
1
I
Blocked radiator
I
Blocked condenser
I
Blocked radiator grille
I
Blocked bumper
I
Visual
No blocking
—
2
I
Coolant mixture
I
Coolant tester
50 - 50% coolant mixture
See “RECOMMENDED
FLUIDS AND LUBRI-
CANTS” in MA section
3
I
Coolant level
I
Visual
Coolant up to MAX level
in reservoir tank and
radiator filler neck
See “Changing Engine
Coolant”, “ENGINE MAIN-
TENANCE” in MA section
4
I
Radiator cap
I
Pressure tester
98 - 118 kPa
(1.0 - 1.2 kg/cm
2
, 14 - 17
psi)
59 - 118 kPa
(0.6 - 1.2 kg/cm
2
, 9 - 17
psi) (Limit)
See “System Check”
“ENGINE COOLING SYS-
TEM” in LC section
ON*
2
5
I
Coolant leaks
I
Visual
No leaks
See “System Check”
“ENGINE COOLING SYS-
TEM” in LC section
ON*
2
6
I
Thermostat
I
Touch the upper and
lower radiator hoses
Both hoses should be hot
See “Thermostat” and
“Radiator”, “ENGINE
COOLING SYSTEM” in
LC section
ON*
1
7
I
Cooling fan
I
CONSULT-II
Operating
See “TROUBLE DIAGNO-
SIS FOR OVERHEAT”
(EC-503)
OFF
8
I
Combustion gas leak
I
Color checker
chemical tester
4 Gas analyzer
Negative
—
ON*
3
9
I
Coolant temperature
gauge
I
Visual
Gauge less than 3/4
when driving
—
I
Coolant overflow to res-
ervoir tank
I
Visual
No overflow during driving
and idling
See “Changing Engine
Coolant”, “ENGINE MAIN-
TENANCE” in MA section
OFF*
4
10
I
Coolant return from res-
ervoir tank to radiator
I
Visual
Should be initial level in
reservoir tank
See “ENGINE MAINTE-
NANCE” in MA section
OFF
11
I
Cylinder head
I
Straight gauge feeler
gauge
0.1 mm (0.004 in) Maxi-
mum distortion (warping)
See “Inspection”, “CYLIN-
DER HEAD” in EM sec-
tion
12
I
Cylinder block and pis-
tons
I
Visual
No scuffing on cylinder
walls or piston
See “Inspection”, “CYLIN-
DER BLOCK” in EM sec-
tion
*1: Turn the ignition switch ON.
*2: Engine running at 3,000 rpm for 10 minutes.
*3: Drive at 90 km/h (55 MPH) for 30 minutes and then let idle for 10 minutes.
*4: After 60 minutes of cool down time.
For more information, refer to “OVERHEATING CAUSE ANALYSIS” in LC section.
