Infiniti M45 (Y34). Manual - part 559





GI-1

GENERAL INFORMATION

A  GENERAL INFORMATION

CONTENTS

C

D

E

F

G

H

I

J

K

L

M

B

GI

SECTION

GI

1

GENERAL INFORMATION

PRECAUTIONS .......................................................... 3

Description ............................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS) (If
Equipped) ................................................................. 3
General Precautions  ................................................ 4
Precautions for Three Way Catalyst ......................... 5
Precautions for Fuel (Unleaded Premium Gasoline
Required) ................................................................. 5
Precautions for Multiport Fuel Injection System or
Engine Control System  ............................................ 6
Precautions for Hoses  .............................................. 6

HOSE REMOVAL AND INSTALLATION  ............... 6
HOSE CLAMPING  ................................................ 6

Precautions for Engine Oils ...................................... 7

HEALTH PROTECTION PRECAUTIONS ............. 7
ENVIRONMENTAL PROTECTION PRECAU-
TIONS ................................................................... 7

Precautions for Air Conditioning ............................... 7

HOW TO USE THIS MANUAL  ................................... 8

Description ............................................................... 8
Terms ....................................................................... 8
Units ......................................................................... 8
Contents ................................................................... 8
Components ............................................................. 9

SYMBOLS ............................................................. 9

How to Follow Trouble Diagnoses .......................... 10

DESCRIPTION .................................................... 10
HOW TO FOLLOW TEST GROUPS IN TROU-
BLE DIAGNOSES  ............................................... 10
HARNESS WIRE COLOR AND CONNECTOR
NUMBER INDICATION  ........................................11
KEY TO SYMBOLS SIGNIFYING MEASURE-
MENTS OR PROCEDURES ............................... 12

How to Read Wiring Diagrams  ............................... 14

CONNECTOR SYMBOLS ................................... 14

SAMPLE/WIRING DIAGRAM - EXAMPL - .......... 15
DESCRIPTION .................................................... 16

Abbreviations .......................................................... 22

SERVICE INFORMATION FOR ELECTRICAL INCI-
DENT ......................................................................... 23

How to Check Terminal ........................................... 23

CONNECTOR AND TERMINAL PIN KIT  ............ 23
HOW TO PROBE CONNECTORS ...................... 23

How to Perform Efficient Diagnosis for an Electrical
Incident ................................................................... 26

WORK FLOW  ...................................................... 26
INCIDENT SIMULATION TESTS  ........................ 26
CIRCUIT INSPECTION  ....................................... 29

Control Units and Electrical Parts  ........................... 34

PRECAUTIONS .................................................. 34

CONSULT-II CHECKING SYSTEM  .......................... 36

Description .............................................................. 36
Function and System Application  ........................... 36
Nickel Metal Hydride Battery Replacement  ............ 36
Checking Equipment  .............................................. 37
CONSULT-II Start Procedure .................................. 37
CONSULT-II Data Link Connector (DLC) Circuit  .... 38

INSPECTION PROCEDURE  .............................. 39

LIFTING POINT ......................................................... 40

Special Service Tools  ............................................. 40
Garage Jack and Safety Stand ............................... 40
2-pole Lift ................................................................ 41
Board-on Lift  ........................................................... 42

TOW TRUCK TOWING  ............................................. 43

Tow Truck Towing  ................................................... 43
Vehicle Recovery (Freeing a Stuck Vehicle) ........... 44

TIGHTENING TORQUE OF STANDARD BOLTS  .... 45

Tightening Torque Table  ......................................... 45

RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS ............................................................... 46

Recommended Chemical Products and Sealants ... 46

IDENTIFICATION INFORMATION  ............................ 47

Model Variation ....................................................... 47

IDENTIFICATION NUMBER ................................ 48

1.

PRECAUTIONS

GI-3

C

D

E

F

G

H

I

J

K

L

M

B

GI

PRECAUTIONS

PFP:00001

Description

AAS0005J

Observe the following precautions to ensure safe and proper servicing. These precautions are not
described in each individual section.

Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”

AAS0007A

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.

WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.

Precautions for NVIS/IVIS (NISSAN/INFINITI VEHICLE IMMOBILIZER SYSTEM -
NATS) (If Equipped)

AAS0005L

NVIS/IVIS (NATS) will immobilize the engine if someone tries to start it without the registered key of NVIS/IVIS
(NATS).
Both of the originally supplied ignition key IDs have been NVIS/IVIS (NATS) registered.
The security indicator is located on the instrument panel. The indicator blinks when the immobilizer system is
functioning.
Therefore, NVIS/IVIS (NATS) warns outsiders that the vehicle is equipped with the anti-theft system.

When NVIS/IVIS (NATS) detects trouble, the security indicator lamp lights up while ignition switch is in
"ON" position.
This lighting up indicates that the anti-theft is not functioning, so prompt service is required.

When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
other NVIS/IVIS (NATS) ignition key IDs), CONSULT-II hardware and CONSULT-II NVIS/IVIS (NATS)
software is necessary.
Regarding the procedures of NVIS/IVIS (NATS) initialization and NVIS/IVIS (NATS) ignition key ID regis-
tration, refer to CONSULT-II operation manual, NVIS/IVIS (NATS).

Therefore, CONSULT-II NVIS/IVIS (NATS) software (program card and operation manual) must be kept
strictly confidential to maintain the integrity of the anti-theft function.

When servicing NVIS/IVIS (NATS) (trouble diagnoses, system initialization and additional registration of
other NVIS/IVIS (NATS) ignition key IDs), it may be necessary to re-register original key identification.
Therefore, be sure to receive all keys from vehicle owner. A maximum of four or five key IDs can be regis-
tered into NVIS/IVIS (NATS).

When failing to start the engine first time using the key of NVIS/IVIS (NATS), start as follows.

1.

Leave the ignition key in "ON" position for approximately 5 seconds.

2.

Turn ignition key to "OFF" or "LOCK" position and wait approximately 5 seconds.

3.

Repeat step 1 and 2 again.

4.

Restart the engine while keeping the key separate from any others on key-chain.

GI-4

PRECAUTIONS

General Precautions

AAS0005M

Do not operate the engine for an extended period of time without
proper exhaust ventilation.
Keep the work area well ventilated and free of any inflammable
materials. Special care should be taken when handling any
inflammable or poisonous materials, such as gasoline, refriger-
ant gas, etc. When working in a pit or other enclosed area, be
sure to properly ventilate the area before working with hazard-
ous materials.
Do not smoke while working on the vehicle.

Before jacking up the vehicle, apply wheel chocks or other tire
blocks to the wheels to prevent the vehicle from moving. After
jacking up the vehicle, support the vehicle weight with safety
stands at the points designated for proper lifting before working
on the vehicle.
These operations should be done on a level surface.

When removing a heavy component such as the engine or tran-
saxle/transmission, be careful not to lose your balance and drop
them. Also, do not allow them to strike adjacent parts, especially
the brake tubes and master cylinder.

Before starting repairs which do not require battery power:
Turn off ignition switch.
Disconnect the negative battery terminal.

If the battery terminals are disconnected, recorded memory of
radio and each control unit is erased.

To prevent serious burns:
Avoid contact with hot metal parts.
Do not remove the radiator cap when the engine is hot.

Dispose of drained oil or the solvent used for cleaning parts in
an appropriate manner.

Do not attempt to top off the fuel tank after the fuel pump nozzle
shuts off automatically.
Continued refueling may cause fuel overflow, resulting in fuel
spray and possibly a fire.

Clean all disassembled parts in the designated liquid or solvent
prior to inspection or assembly.

Replace oil seals, gaskets, packings, O-rings, locking washers, cotter pins, self-locking nuts, etc. with new
ones.

Replace inner and outer races of tapered roller bearings and needle bearings as a set.

Arrange the disassembled parts in accordance with their assembled locations and sequence.

Do not touch the terminals of electrical components which use microcomputers (such as ECM).
Static electricity may damage internal electronic components.

After disconnecting vacuum or air hoses, attach a tag to indicate the proper connection.

Use only the fluids and lubricants specified in this manual.

SGI285

SGI231

SEF289H

SGI233
