SERVICE DATA AND SPECIFICATIONS (SDS)
EX-11
C
D
E
F
G
H
I
J
K
L
M
A
EX
SERVICE DATA AND SPECIFICATIONS (SDS)
PFP:00030
Tightening Torque
ABS00A3N
Unit: N·m (kg-m, ft-lb)
Unit: N·m (kg-m, in-lb)*
Exhaust system connections
Between exhaust manifold and exhaust front tube
Between exhaust front tube and center muffler
Between center muffler and main muffler
Exhaust mounting fixing bolts
For exhaust front tube
For center muffler
Heated oxygen sensor 2 (bank 1) (bank 2)
52.5 (5.4, 39)
57.9 (5.9, 43)
34.8 (3.5, 26)
28.5 (2.9, 21)
14.2 (1.4, 10)
50.0 (5.1, 37)
Dual mode muffler
Muffler control unit
Actuator
Actuator mounting bracket
Actuator cover
Cable lock nut (Both actuator and valve side)
Cable middle clamp tightening bolt
5.0 - 6.47 (0.51 - 0.65, 45 - 57)*
5.0 - 6.47 (0.51 - 0.65, 45 - 57)*
14.7 - 18.6 (1.5 - 1.8, 11 - 13)
5.0 - 6.47 (0.51 - 0.65, 45 - 57)*
25.5 - 33.3 (2.6 - 3.3, 19 - 24)
5.0 - 6.47 (0.51 - 0.65, 45 - 57)*
