ON BOARD REFUELING VAPOR RECOVERY (ORVR) EC-701 C D E F G H I J K L M A EC 8. CHECK REFUELING CONTROL VALVE Refer to EC-701, "Component Inspection" OK or NG OK >> GO TO 9. NG >> Replace refueling control valve with fuel tank. 9. CHECK REFUELING EVAP VAPOR CUT VALVE Refer to EC-701, "Component Inspection" OK or NG OK >> GO TO 10. NG >> Replace refueling EVAP vapor cut valve with fuel tank. 10. CHECK FUEL FILLER TUBE Check filler neck tube and hose connected to the fuel tank for clogging, dents and cracks. OK or NG OK >> GO TO 11. NG >> Replace fuel filler tube. 11. CHECK ONE-WAY FUEL VALVE-I Check one-way valve for clogging. OK or NG OK >> GO TO 12. NG >> Repair or replace one-way fuel valve with fuel tank. 12. CHECK ONE-WAY FUEL VALVE-II 1. Make sure that fuel is drained from the tank. 2. Remove fuel filler tube and hose. 3. Check one-way fuel valve for operation as follows. OK or NG OK >> INSPECTION END NG >> Replace fuel filler tube or replace one-way fuel valve with fuel tank. Component Inspection ABS002UH WATER SEPARATOR 1. Check visually for insect nests in the water separator air inlet. 2. Check visually for cracks or flaws in the appearance. 3. Check visually for cracks or flaws in the hose. SEF665U |
