COMBINATION SWITCH LT-241 C D E F G H I J L M A B LT 4. CHECK BCM OUTPUT TERMINAL 1. Connect BCM and combination switch connectors. 2. Turn ignition switch ON. 3. Turn lighting switch and wiper switch into OFF. 4. Set wiper dial position 4. 5. Check BCM output terminal voltage waveform of suspect mal- OK or NG OK >> Open circuit in combination switch, GO TO 5. NG BCS-15, "Removal and Installation of BCM" . 5. CHECK COMBINATION SWITCH Referring to table below, perform combination switch inspection. >> INSPECTION END Removal and Installation NKS003SA Refer to LT-230, "LIGHTING AND TURN SIGNAL SWITCH" . Suspect system Terminal Reference value (+) (-) Combina- tion switch connector Terminal 1 M29 1 Ground Approx. 7.0 - 7.5 V 2 2 3 3 4 4 5 5 SKIB4820E PKIB4960J Procedure 1 2 3 4 5 6 7 Replace lighting switch Confirm OK INSPECTION END Confirm OK INSPECTION END Confirm OK INSPECTION END NG Replace wiper NG Replace switch NG Check symptom |
