QUICK REFERENCE CHART M35/M45

PFP:00000

ENGINE TUNE-UP DATA (VQ35DE)

ELS0003W

*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on belt.

Engine model

VQ35DE

Firing order

1-2-3-4-5-6

Idle speed
A/T (In “P” or “N” position)

rpm

650

Ignition timing (BTDC at idle speed)
A/T (In “P” or “N” position)

CO% at idle

0.7 - 9.9% and engine runs smoothly

Drive Belt

Deflection adjustment Unit: mm
(in)

Tension adjustment* Unit: N (kg, lb)

Used belt

New belt

Used belt

New belt

Limit

After adjustment

Limit

After adjustment

Alternator and
power steering
oil pump belt

With idler pulley 1

7 (0.28)

4 - 5

(0.16 - 0.20)

3.5 - 4.5

(0.138 - 0.177)

294 (30, 66)

730 - 818

(74.5 - 83.4,

164 - 184)

838 - 926

(85.5 - 94.5,

188 - 208)

Without idler pul-
ley 1

12 (0.47)

7 - 8

(0.28 - 0.31)

6 - 7

(0.24 - 0.28)

A/C compresor belt

12 (0.47)

9 - 10

(0.35 - 0.39)

8 - 9

(0.31 - 0.35)

196 (20, 44)

348 - 436

( 35.5 - 44.5,

78 - 98)

470 - 559
(48 - 57,

106 - 126)

Applied pushing force

98N (10kg, 22lb)

—

Radiator cap relief pressure

kPa (kg/cm

, psi)

Standard

78 - 98 (0.8 - 1.0, 11 - 14)

Limit

59 (0.6, 9)

Cooling system leakage testing
pressure

kPa (kg/cm

, psi)

157 (1.6, 23)

Compression pressure

kPa (kg/cm

, psi)/rpm

Standard

1,275 (13.0, 185) /300

Minimum

981 (10.0, 142) /300

Spark plug

Standard type

PLFR5A-11

Hot type

PLFR4A-11

Cold type

PLFR6A-11

2007

QUICK REFERENCE CHART M35/M45

ENGINE TUNE-UP DATA (VK45DE)

FRONT WHEEL ALIGNMENT (Unladen* )

ELS0003X

Engine model

VK45DE

Firing order

1-8-7-3-6-5-4-2

Idle speed
A/T (In “P” or “N” position)

rpm

650

Ignition timing
(BTDC at idle speed)

CO% at idle

0.7 - 9.9% and engine runs smoothly

Tensions of drive belts

Auto adjustment by auto tensioner

Radiator cap relief pressure

kPa (kg/cm

, psi)

78 - 98 (0.8 - 1.0 , 11 - 14)

Standard

Limit

59 (0.6, 9)

Cooling system leakage testing pressure

157 (1.6, 23)

kPa (kg/cm

, psi)

Compression pressure

kPa (kg/cm

, psi)/rpm

1,320 (13.5, 191) /300

Standard

Minimum

1,130 (11.5, 164) /300

Spark plug

Standard type

PLFR5A-11

Hot type

PLFR4A-11

Cold type

PLFR6A-11

Axle

2WD

AWD

Tire

245/45R18

245/40R19

245/45R18

Camber
Degree minute (Decimal degree)

Minimum

–1

′

(–1.00

)

Nominal

–0

′

(–0.25

)

Maximum

′

(0.50

)

Left and right difference

′

(0.55

) or less

Caster
Degree minute (Decimal degree)

Minimum

′

( 3.75

)

′

(3.83

)

′

( 3.08

)

Nominal

′

( 4.50

)

′

(4.58

)

′

( 3.83

)

Maximum

′

( 5.25

)

′

(5.33

)

′

( 4.58

)

Left and right difference

′

(0.65

) or less

Kingpin inclination
Degree minute (Decimal degree)

Minimum

′

(6.50

)

Nominal

′

(7.25

)

Maximum

′

(8.00

)

Total toe-in

Distance

Minimum

0 mm (0 in)

Nominal

1 mm (0.04 in)

Maximum

2 mm (0.08 in)

Angle
(left wheel or right wheel)
Degree minute
(Decimal degree)

Minimum

′

)

Nominal

′

(0.05

)

Maximum

′

(0.10

)

2007

QUICK REFERENCE CHART M35/M45

* : Fuel, engine coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

REAR WHEEL ALIGNMENT (Unladen*)

ELS0003Y

* : Fuel, engine coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

BRAKE

ELS0003Z

* : Under force of 490 N ( 50 kg, 110 lb ) with engine running.

REFILL CAPACITIES

ELS00040

Wheel
turning
angle (Full
turn)

Inside
Degree minute
(Decimal degree)

Minimum

′

(36.3

)

′

(39.8

)

Nominal

′

(39.3

)

′

(42.8

)

Maximum

′

(40.3

)

′

(43.8

)

Outside
Degree minute
(Decimal degree)

Nominal

′

(33.4

)

′

(33.3

)

′

(32.5

)

Axle

2WD

AWD

Tire

245/45R18

245/40R19

245/45R18

Axle

2WD

AWD

Tire

245/45R18

245/40R19

245/45R18

Camber
Degree minute (Decimal degree)

Minimum

–1

′

(–1.17

)

–1

′

(–1.33

)

–0

′

(–0.67

)

Nominal

–0

′

(–0.67

)

–0

′

(–0.83

)

–0

′

(–0.17

)

Maximum

–0

′

(–0.17

)

–0

′

(–0.33

)

′

(0.33

)

Total toe-in

Distance

Minimum

0.1 mm (0.004 in)

Nominal

2.8 mm (0.110 in)

Maximum

5.5 mm (0.217 in)

Angle
(left wheel or right wheel )
Degree minute
(Decimal degree)

Minimum

′

)

Nominal

′

(0.12

)

Maximum

′

(0.23

)

Front brake

Repair limit thickness

2.0 mm (0.079 in)

Wear limit

26.0 mm (1.024 in)

Rear brake

Repair limit thickness

2.0 mm (0.079 in)

Wear limit

14.0 mm (0.551 in)

Brake pedal height

157 - 167 mm (6.18 - 6.57 in)

Depressed pedal height*

90 mm (3.54 in) or more

UNIT

Liter

US measure

Fuel tank

20 gal

Coolant ( With reservoir tank )

VQ35DE

8.9

9 - 3/8 qt

VK45DE

10.4

11 qt

Engine (VQ35DE)

Drain and refill

With oil filter change

4.7

5 qt

Without oil filter change

4.4

4 - 5/8 qt

Dry engine (Overhaul)

5.4

5 - 3/4 qt

Engine (VK45DE)

Drain and refill

With oil filter change

5.5

5 - 3/4 qt

Without oil filter change

4.9

5 - 1/8 qt

Dry engine (Overhaul)

6.7

7 - 1/8 qt

2007

QUICK REFERENCE CHART M35/M45

Transmission

A/T

10.3

10 - 7/8 qt

Transfer

1.25

2 - 5/8 pt

Differential carrier

Front

0.65

1 - 3/8 pt

Rear

1.4

3 pt

Power steering system

1.0

1 - 1/8 qt

Air conditioning system

Compressor oil

0.15

5.03 fl oz

Refrigerant

0.55 kg

1.21 lb

UNIT

Liter

US measure

2007
