SERVICE DATA AND SPECIFICATIONS (SDS)
PFP:00030
General Specifications
NDS000EW
Inspection and Adjustment
NDS000EX
DRIVE GEAR RUNOUT
Unit: mm (in)
DIFFERENTIAL SIDE GEAR CLEARANCE
Unit: mm (in)
PRELOAD TORQUE
Unit: N·m (kg-m, in-lb)
BACKLASH
Unit: mm (in)
COMPANION FLANGE RUNOUT
Unit: mm (in)
SELECTIVE PARTS
Side Gear Thrust Washer
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Applied model
VQ35DE
Final drive model
F160A
Gear ratio
3.692
Number of teeth (Drive gear/Drive pinion)
48/13
Oil capacity (Approx.)
(US pt, lmp pt)
0.65 (1-3/8, 1-1/8)
Number of pinion gears
2
Drive pinion adjustment spacer type
Solid
Item
Runout limit
Drive gear back face
0.05 (0.0020)
Item
Specification
Side gear backlash (Clearance between side gear and differential
case)
0.2 (0.008) or less
(Each gear should rotate smoothly without excessive resistance
during differential motion.)
Item
Specification
Pinion bearing (P
1
)
0.78 - 1.57 (0.08 - 0.16, 7 - 13)
Side bearing (P
2
)
0.78 - 1.08 (0.08 - 0.11, 7 - 9)
Side bearing to pinion bearing (Total preload)
(Total preload = P
1
+ P
2
)
1.56 - 2.65 (0.16 - 0.27, 14 - 23)
Item
Specification
Drive gear to drive pinion gear
0.10 - 0.15 (0.0039 - 0.0059)
Item
Runout limit
Companion flange face
0.18 (0.0070)
Inner side of the companion flange
0.13 (0.0051)
Thickness
Part number*
Thickness
Part number*
0.68 (0.0268)
0.71 (0.0280)
0.74 (0.0291)
0.77 (0.0303)
0.80 (0.0315)
0.83 (0.0327)
38424 W1010
38424 W1011
38424 W1012
38424 W1013
38424 W1014
38424 W1015
0.86 (0.0339)
0.89 (0.0350)
0.92 (0.0362)
0.95 (0.0374)
0.98 (0.0386)
1.01 (0.0398)
38424 W1016
38424 W1017
38424 W1018
38424 W1019
38424 W1020
38424 W1021
