DTC P0460 FUEL LEVEL SENSOR EC-1169 [VK45DE] C D E F G H I J K L M A EC DTC P0460 FUEL LEVEL SENSOR PFP:25060 Component Description NBS005IP The fuel level sensor is mounted in the fuel level sensor unit. ● Fuel level sensor unit and fuel pump (1) ● Fuel pressure regulator (2) ● Fuel tank temperature sensor (3) On Board Diagnosis Logic NBS005IQ NOTE: ● If DTC P0460 is displayed with DTC U1000 or U1001, first perform the trouble diagnosis for DTC EC-865, "DTC U1000, U1001 CAN COMMUNICATION LINE" . ● If DTC P0460 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. EC-868, "DTC U1010 CAN COMMUNICATION" When the vehicle is parked, naturally the fuel level in the fuel tank is stable. It means that output signal of the DTC Confirmation Procedure NBS005IR NOTE: WITH CONSULT-II 1. Turn ignition switch ON. 2. Select “DATA MONITOR” mode with CONSULT-II. 3. Start engine and wait maximum of 2 consecutive minutes. 4. If 1st trip DTC is detected, go to . WITH GST Follow the procedure “WITH CONSULT-II” above. PBIB2707E DTC No. Trouble diagnosis name DTC detecting condition Possible cause P0460 Fuel level sensor circuit Even though the vehicle is parked, a signal ● Harness or connectors ● Harness or connectors ● Unified meter and A/C amp. ● Fuel level sensor SEF195Y |
