DTC P2122, P2123 APP SENSOR EC-617 [VQ35DE] C D E F G H I J K L M A EC DTC P2122, P2123 APP SENSOR PFP:18002 Component Description NBS0056L The accelerator pedal position sensor is installed on the upper end CONSULT-II Reference Value in Data Monitor Mode NBS0056M Specification data are reference values. *: Accelerator pedal position sensor 2 signal is converted by ECM internally. Thus, it differs from ECM terminal voltage. On Board Diagnosis Logic NBS0056N These self-diagnoses have the one trip detection logic. NOTE: EC-486, "DTC P0643 SENSOR POWER SUPPLY" FAIL-SAFE MODE When the malfunction is detected, ECM enters fail-safe mode and the MIL lights up. PBIB1741E MONITOR ITEM CONDITION SPECIFICATION ACCEL SEN 1 ● Ignition switch: ON Accelerator pedal: Fully released 0.4 - 1.1V Accelerator pedal: Fully depressed 3.7 - 4.8V CLSD THL POS ● Ignition switch: ON Accelerator pedal: Fully released ON Accelerator pedal: Slightly depressed OFF DTC No. Trouble diagnosis name DTC detecting condition Possible cause P2122 Accelerator pedal posi- An excessively low voltage from the APP sen- ● Harness or connectors ● Accelerator pedal position sensor P2123 Accelerator pedal posi- An excessively high voltage from the APP sen- Engine operating condition in fail-safe mode The ECM controls the electric throttle control actuator in regulating the throttle opening in order for the idle position to be within +10 |
