INTELLIGENT KEY SYSTEM
BL-49
C
D
E
F
G
H
J
K
L
M
A
B
BL
Key Reminder Function
Key reminder functions have the following 3 functions.
*:If the door closing impact shocks the door lock knob, or contacts against baggage with the door lock knob might activate the door locks
accidentally but unlock operation will be perform at these cases.
CAUTION:
●
The above function operates when the Intelligent Key is inside the vehicle. However, there may be
times when the Intelligent Key cannot be detected, and this function will not operate when the
Intelligent Key is on the instrument panel, rear parcel shelf, or in the glove box. Also, this system
sometimes does not operate if the Intelligent Key is in the door pocket for the open door.
●
When the key reminder function is operated when the trunk is open/closed and the buzzers sound,
if the following operations are performed, the key reminder function is cleared and buzzer sounds
are stopped.
–
Remote controller door lock button operation of Intelligent Key
–
Remote controller door unlock button operation of Intelligent Key
–
When the trunk is closed, the Intelligent Key is not inside the vehicle
–
When any door is open
Selective Unlock Function
When an LOCK signal is sent from door request switch (driver side or passenger side), all doors will be locked.
When an UNLOCK signal is sent from door request switch (driver side or passenger side) once, driver's door
will be unlocked.
Then, if an UNLOCK signal is sent from door request switch (driver side and passenger side) again within 5
seconds, all other door will be unlocked.
Hazard and Buzzer Reminder Function
During lock, unlock, or trunk opening operation by each request switch, the hazard warning lamps and Intelli-
gent Key warning buzzer will flashes or honk as a reminder.
When doors are locked, unlocked or trunk open by each request switch, Intelligent Key unit honks Intelligent
Key warning buzzer as a reminder and sends hazard request signal to BCM via CAN communication line.
BCM flashes hazard warning lamps as a reminder.
Operating function of hazard and buzzer reminder
How to change hazard and buzzer reminder mode
With CONSULT-II
Key remainder function
Operation condition
Operation
Driver door close*
Right after driver side door is closed under the following conditions
●
Door lock operation is performed
●
Driver side door is opened
●
Driver side door is in unlock state
All doors unlock
Door is open or closed
Right after all doors are closed under the following conditions
●
Intelligent Key is inside the vehicle
●
Any door is opened
●
All doors are locked by door lock and unlock switch or door lock knob
●
All doors unlock
●
Honk Intelligent Key warning
buzzer
Trunk is closed
Right after trunk is closed under the following conditions
●
Intelligent Key is inside trunk room
●
all doors are closed
●
all doors are locked
●
Trunk open
●
Honk Intelligent Key warning
buzzer
Operation
Hazard warning lamp flash
Intelligent Key warning buzzer honk
Unlock
Once
Once
Lock
Twice
Twice
Trunk open
—
Fourth
