Infiniti M35/M45 Y50. Manual - part 207





TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

AV-205

[WITH MOBILE ENTERTAINMENT SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

AV

*: BOSE surround 5.1ch system

CAUTION:

When the stereo sound is played, only front RH and LH are input. When the monaural sound is played, only center is input. All
surround sounds are input only when the 5.1 channel surround sound is played.

59

*

(B)

72

*

(W)

Audio signal rear sur-
round LH

Output

ON

Receive audio signal.

62

*

(G/Y)

73

*

(GR/R)

Audio signal rear sur-
round RH

Output

ON

Receive audio signal.

63

*

(B/W)

74

*

(L)

Audio signal driver seat
LH

Output

ON

Receive audio signal.

64

*

(B/R)

75

*

(BR)

Audio signal driver seat
RH

Output

ON

Receive audio signal.

68

(O)

55

(B/P)

Audio signal rear RH

Output

ON

Receive audio signal.

71

*

(Y)

70

*

(BR)

Audio signal passenger
seat RH

Output

ON

Receive audio signal.

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

+

Ignition

switch

Operation

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-206

[WITH MOBILE ENTERTAINMENT SYSTEM]

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

Satellite Radio Tuner

NKS004AN

Terminal

(Wire color)

Item

Signal
 input/
output

Condition

Reference value

+

Ignition

switch

Operation

2

(R)

1

(G)

Audio signal LH

Output

ON

Receive audio signal.

4

(B)

3

(W)

Audio signal RH

Output

ON

Receive audio signal.

5

Shield

6

Shield

8

(R/W)

Ground

REQ1 (SAT-AUDIO)

Output

ON

Set to the satellite radio
mode

9

(B)

Ground

Communication signal
(SAT-AUDIO)

Output

ON

Set to the satellite radio
mode

10

(R)

Ground

Communication signal
(AUDIO-SAT)

Input

ON

Set to the satellite radio
mode

12

(BR/Y)

Ground

Battery power supply

Input

OFF

Battery voltage

16

(BR)

Ground

ACC power supply

Input

ACC

Battery voltage

20

Satellite antenna signal

Input

SKIB3609E

SKIB3609E

SKIB3825E

SKIB3824E

SKIB3826E

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

AV-207

[WITH MOBILE ENTERTAINMENT SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

AV

AV (NAVI) Control Unit

NKS004AO

Terminal

(Wire color)

Item

Signal

Input/

output

Condition

Reference value

+

Ignition

switch

Operation

1

(B)

Ground

Ground

ON

Approx. 0 V

2

(Y)

Ground

Battery power supply

Input

OFF

Battery voltage

5

(V)

Ground

ACC power supply

Input

ACC

Battery voltage

6

(O/L)

7

MIC. VCC

Output

ON

Approx. 5 V

7

Ground

MIC. ground

ON

Approx. 0 V

8

(W/L)

7

MIC. signal

Input

ON

Give a voice.

9

Shield

10

(BR)

11

(B/R)

TEL voice signal

Output

ON

When inputting TEL voice.

12

(L/G)

14

(L/Y)

Voice guidance signal

Output

ON

When inputting voice guid-
ance.

13

Shield

44

(L/G)

47

(W/L)

RGB signal (R: red)

Output

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

45

(O/L)

47

(W/L)

RGB signal (G: green)

Output

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

PKIB5037J

SKIB3609E

SKIB3609E

SKIB2238J

SKIB2236J

AV-208

[WITH MOBILE ENTERTAINMENT SYSTEM]

TERMINALS AND REFERENCE VALUE FOR CONTROL UNIT

46

(L/Y)

47

(W/L)

RGB signal (B: blue)

Output

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

47

(W/L)

Ground

RGB ground

ON

Approx. 0 V

48

(B)

Ground

RGB synchronizing sig-
nal

Output

ON

49

Shield

50

(G)

Ground

RGB area (YS) signal

Output

ON

When inputting RGB image.

Approx. 5 V

Set the selector lever in R
position, and then display
the rear view  image.

51

(W)

Ground

Horizontal synchronizing
(HP) signal

Input

ON

52

(R)

Ground

Vertical synchronizing
(VP) signal

Input

ON

53

(O/L)

Ground

Communication signal
(CONT-DISP)

Input

ON

When adjusting display
brightness.

Terminal

(Wire color)

Item

Signal

Input/

output

Condition

Reference value

+

Ignition

switch

Operation

SKIB2237J

SKIB3603E

PKIB4948J

SKIB3601E

SKIB3598E

PKIB5039J
