FRONT DISPLAY UNIT
●
It receives the RGB signal and the image signal of DVD player
and camera control unit from AV (NAVI) control unit.
●
The changing of image is controlled by the communication with
AV (NAVI) control unit.
DVD PLAYER
●
It sends the sound signal to the BOSE amp and sends the
image signal to the front display unit.
●
When the downmix function is turned ON when playing DVD,
the sound signal is sent to the audio unit.
●
It inputs the sound signal from auxiliary input jacks, and then
sends it to audio unit.
CAMERA CONTROL UNIT
●
When the reverse signal is input, the power is supplied to the
rear view camera, and then the image signal from the rear view
camera is sent to the front display unit.
●
The camera control unit displays the guiding lines and possible
route lines, and then it synthesizes them to the camera image.
CAN Communication System Description
NKS0048B
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Unit
NKS0048C
Refer to
LAN-50, "CAN System Specification Chart"
.
