SYSTEM DESCRIPTION

STC-17

[RAS]

STC

Fail-Safe Function

NGS000EA

In the event there is a malfunction with the electrical system, the RAS control is stopped and the fail-safe
mode is activated. At that time, it indicates the malfunction by turning the RAS warning lamp ON and stops the
rear wheel control.

STC-18

[RAS]

TROUBLE DIAGNOSIS

PFP:00004

How to Perform Trouble Diagnosis

NGS000EB

BASIC CONCEPT

●

The most important point to perform trouble diagnosis is to understand systems (control and mechanism)
in vehicle thoroughly.

●

It is also important to clarify customer complaints before inspec-
tion.
First of all, reproduce symptom, and understand it fully.
Ask customer about his/her complaints carefully. In some cases,
they will be necessary to check symptom by driving vehicle with
customer.

CAUTION:

Customers are not professionals. Do not assume “maybe
customer means...” or “maybe customer mentioned this
symptom”.

●

It is essential to check symptoms right from beginning in order to
repair a malfunction completely.
For an intermittent malfunction, it is important to reproduce
symptom based on interview with customer and past examples.
Do not perform inspection on ad hoc basis. Most intermittent
malfunctions are caused by poor contacts. In this case, it will be
effective to shake suspected harness or connector by hand.
When repairs are performed without any symptom check, no
one can judge if malfunction has actually been eliminated.

●

After diagnosis, make sure to perform “ERASE MEMORY”.
Refer to

STC-29, "How to Erase Self-Diagnostic Results"

●

Always read “GI General Information” to confirm general precau-
tions. Refer to

GI-4, "General Precautions"

EFJ0028D

SEF233G
