Infiniti F50. Manual - part 760





AUTOMATIC DRIVE POSITIONER

SE-31

C

D

E

F

G

H

J

K

L

M

A

B

SE

Terminals and Reference Values for BCM

EIS0041G

TIWM0089E

Termi-

nal

WIRE

COLOR

ITEM

CONDITION

VOLTAGE (V)

(Approx.)

8

G/OR

Detente switch signal

Insert the key

Selector lever in
 P-position.

 0

Selector lever in other
than P-position.

Battery voltage

17

BR/Y

Data link (RX line)

18

P

Data link (TX line)

22

R

Telescopic switch

FR

signal

Telescoping switch

Forward operation
(Motor operated)

 0

OFF

5

SE-32

AUTOMATIC DRIVE POSITIONER

23

PU/W

Tilt switch DOWN sig-
nal

Tilt switch

DOWN operation
(Motor operated)

 0

OFF

5

26

GY/R

Telescopic switch
backward signal

Telescoping switch

Backward operation
(Motor operated)

0

OFF

5

30

PU

Monitor line (TX)

31

LG

Monitor line (RX)

36

Y/G

Tilt switch UP signal

Tilt switch

UP operation
(Motor operated)

0

OFF

5

39

G

Memory switch 1 sig-
nal

Memory switch 1

ON

0

OFF

5

43

O

Memory switch 2 sig-
nal

Memory switch 2

ON

 0

OFF

5

46

P/L

Tilt sensor signal

Tilt position, top

2

Tilt position, bottom

4

49

PU/W

Vehicle speed signal
(2-pulse)

When vehicle speed is approx. 40 km/h (25
MPH).

50

R/Y

Seat memory setting
switch signal

Setting switch

ON

0

OFF

5

53

L/W

Tilt and telescopic
sensor ground

Ignition switch ON

0

54

LG/B

Tilt and telescopic
sensor power supply

Ignition switch OFF

5

55

B/W

IGN power supply

Ignition switch START

Battery voltage

56

B

ground

Ignition switch ON

0

60

L/OR

ACC power supply

Ignition switch ACC

Battery voltage

61

R/B

Date line A-1

62

P/B

Telescopic sensor
signal

Telescoping position, top

2

 Telescoping position, bottom

4

67

G/W

Date line A-3

68

W/B

IGN power supply

Ignition switch ON or START

Battery voltage

69

PU/W

Key switch signal

Insert the key (ON).

Battery voltage

Remove the key (OFF).

0

101

R/W

Telescopic motor
forward signal

Telescoping switch

ON (forward opera-
tion)

Battery voltage

 OFF

0

102

P

Tilt motor DOWN
signal

Tilt switch

ON
(DOWN operation)

Battery voltage

OFF

0

Termi-

nal

WIRE

COLOR

ITEM

CONDITION

VOLTAGE (V)

(Approx.)

ELF1080D

AUTOMATIC DRIVE POSITIONER

SE-33

C

D

E

F

G

H

J

K

L

M

A

B

SE

Terminals and Reference Values for Driver Seat Control Unit

EIS0041H

103

R/B

Tilt motor UP signal

Tilt switch

ON (UP operation)

Battery voltage

OFF

0

104

Y/B

Power supply for tilt
and telescopic device

Ignition switch OFF

Battery voltage

105

Y/L

Battery power supply

Ignition switch OFF

Battery voltage

106

BR/Y

Power seat memory
indicator 1 signal

Indicator 1

ON

 0

OFF

Battery voltage

107

R

Telescopic motor
backward signal.

Telescoping switch

ON (backward opera-
tion)

Battery voltage

OFF

 0

112

L/W

Power seat memory
indicator 2 signal

Indicator 2

ON

0

OFF

Battery voltage

113

B

Ground

Ignition switch ON

0

114

B

Ground for tilt and
telescoping device

Ignition switch ON

0

142

W/R

Driver door switch sig-
nal

Driver door open (ON)

 0

Driver door closed (OFF)

Battery voltage

148

P

Data line A–1

Termi-

nal

WIRE

COLOR

ITEM

CONDITION

VOLTAGE (V)

(Approx.)

TERMI-

NAL

WIRE

COLOR

ITEM

CONDITION

VOLTAGE (V)

(Approx.)

1

W

Sliding motor forward
output signal

Sliding switch

Forward operation
(Motor operated)

Battery voltage

OFF

 0

2

G

Reclining motor for-
ward output signal

Reclining switch

Forward operation
(Motor operated)

Battery voltage

OFF

0

4

Y

Rear lifting motor
DOWN output signal

Rear lifting switch

DOWN operation
(Motor operated)

Battery voltage

OFF

0

6

PU

Rear lifting motor UP
output signal

Rear lifting switch

UP operation
(Motor operated)

Battery voltage

OFF

0

8

BR

Sliding motor back-
ward output signal

Sliding switch

Backward operation
(Motor operated)

Battery voltage

OFF

0

9

LG

Reclining motor back-
ward output signal

Reclining switch

Backward operation
(Motor operated)

Battery voltage

OFF

0

10

OR

Front lifting motor UP
signal

Front lifting switch

UP operation
(Motor operated)

Battery voltage

OFF

0

11

P

Front lifting motor
DOWN output signal

Front lifting switch

DOWN operation
(Motor operated)

Battery voltage

OFF

0

14A

B/W

Ground

Ignition switch ON

 0

15B

B

SE-34

AUTOMATIC DRIVE POSITIONER

16A

R

Battery power supply

Ignition switch OFF

Battery voltage

17

Y/R

Sliding switch

forward

signal

Sliding switch

ON (forward opera-
tion)

0

OFF

5

18

GY/B

Reclining switch
forward signal

Reclining switch

ON (forward opera-
tion)

0

OFF

5

19

L/R

Front lifting switch
UP signal

Front lifting switch

ON (UP operation)

0

OFF

5

20

G/B

Sliding sensor signal

Sliding motor operation

Other than above.

0 or 5

21

Y/B

Front lifting sensor sig-
nal

Front lifting motor operation

Other than above.

0 or 5

22

R/B

Data line A–1

23

G/W

Sliding switch back-
ward input/output

Sliding switch

ON (backward oper-
ation)

0

OFF

0 or 5

24

SB

Reclining switch
backward input/output

Reclining switch

ON (backward oper-
ation)

0

OFF

0 or 5

25

OR/B

Front lifting switch
DOWN signal

Front lifting switch

ON
(DOWN operation)

0

OFF

0 or 5

26

P/B

Rear lifting switch
UP signal

Rear lifting switch

ON (UP operation)

0

OFF

0 or 5

27

B/Y

Rear lifting switch
DOWN signal

Rear lifting switch

ON
(DOWN operation)

0

OFF

0 or 5

30

L

Reclining sensor signal

Reclining motor operation

Other than above.

TERMI-

NAL

WIRE

COLOR

ITEM

CONDITION

VOLTAGE (V)

(Approx.)

SIIA0690J

SIIA0691J

SIIA0692J
