VEHICLE INFORMATION AND INTEGRATED SWITCH SYSTEM /WITH NAVIGA-

TION SYSTEM

DI-151

C

D

E

F

G

H

I

J

L

M

A

B

DI

Terminals and Reference Value for AV and NAVI Control Unit

EKS006EJ

Refer to

AV-73, "Terminals and Reference Value for AV and NAVI Control unit"

 .

Terminals and Reference Value for Display

EKS006TT

Terminals

Signal

Condition

Reference value (V)

(+)

(–)

Terminal

No.

Wire

color

Ignition

switch

Operation

1

L

Ground

RGB signal (R: Red)

ON

Move to “Screen
Adjustment” in the
check/adjustment
function.

2

Y

Ground

RGB signal (G: Green)

ON

Move to “Screen
Adjustment” in the
check/adjustment
function.

3

G

Ground

RGB signal (B: Blue)

ON

Move to “Screen
Adjustment” in the
check/adjustment
function.

4

Ground

RGB ground

ON

Approx. 0

5

L/Y

Ground

Horizontal synchronizing signal

ON

ON screen, the volume
can be adjusted.

6

OR

Ground

Vertical synchronizing signal

ON

7

L/R

Ground

RGB synchronizing signal

ON

Press the map switch.

SKIA0165E

SKIA0166E

SKIA0167E

SKIA0163E

SKIA0161E

SKIA0164E

DI-152

VEHICLE INFORMATION AND INTEGRATED SWITCH SYSTEM /WITH NAVIGA-

TION SYSTEM

8

LG

Ground

RGB area signal

ON

Press the vehicle
information switch.

12

R/L

Ground

Communication signal (-)

ON

13

Y

Ground

Communication signal (+)

ON

14

Shield ground

15

L

Ground

Communication signal (-)

ON

16

R

Ground

Communication signal (+)

ON

17

Ground

Shield ground

19

L/OR

Ground

Ignition switch (ACC)

ACC

Battery voltage

21

SB

Ground

Battery power

OFF

Battery voltage

23

SB

22

B

Ground

Ground

24

B

Terminals

Signal

Condition

Reference value (V)

(+)

(–)

Terminal

No.

Wire

color

Ignition

switch

Operation

SKIA0162E

SKIA0176E

SKIA0175E

SKIA0176E

SKIA0175E

VEHICLE INFORMATION AND INTEGRATED SWITCH SYSTEM /WITH NAVIGA-

TION SYSTEM

DI-153

C

D

E

F

G

H

I

J

L

M

A

B

DI

Terminals and Reference Value for Multifunction Switch

EKS006TU

Terminals

Signal

Condition

Reference value (V)

(+)

(–)

Terminal

No.

Wire

color

Ignition

switch

Operation

1

L/OR

Ground

Ignition switch (ACC)

ACC

Battery voltage

2

B

Ground

Ground

ON

Approx. 0

9

R

Ground

Communication signal
(+)

ON

10

L

Ground

Communication signal
(-)

ON

11

Ground

Shield ground

ON

15

OR

Ground

Communication signal
(+)

ON

16

W

Ground

Communication signal
(-)

ON

17

Ground

Shield ground

SKIA0175E

SKIA0176E

SKIA0175E

SKIA0176E

DI-154

VEHICLE INFORMATION AND INTEGRATED SWITCH SYSTEM /WITH NAVIGA-

TION SYSTEM

On Board Self-Diagnosis Function

EKS006EK

DESCRIPTION

Diagnosis function consists of the self-diagnosis mode performed automatically and the CONFIRMATION/
ADJUSTMENT mode operated manually.

Self-diagnosis mode checks for connections between the units constituting this system, analyzes each
individual unit at the same time, and displays the results on the LCD screen.

CONFIRMATION/ADJUSTMENT mode is used to perform trouble diagnosis that require operation and
judgment by an operator (trouble that cannot be automatically judged by the system), to check/change the
set value, and to display the History of Errors of the navigation system.

DIAGNOSIS ITEM

Self-Diagnosis Mode

EKS006EL

Refer to

DI-109, "Self-Diagnosis Mode"

 .

Confirmation/Adjustment Mode

EKS006EM

Refer to

DI-113, "Confirmation/Adjustment Mode"

 .

CONSULT-ll Function

EKS006EN

Refer to

DI-116, "CONSULT-II Function"

 .

Mode

Description

Self-diagnosis

AV and NAVI Control unit diagnosis (DVD-ROM drive will not be diag-
nosed when no map DVD-ROM is in it.)

Analyzes connection between the AV and NAVI control unit and the GPS
antenna connection between the AV and NAVI control unit and each unit,
and operation of each unit.

CONFIRMATION/
ADJUSTMENT

Display diagnosis

Color tone and shading of the screen can be checked by the display of a
color bar and a gray scale.

Vehicle signals

Analyzes the following vehicle signals: Vehicle speed signal, parking brake
signal, light signal, ignition switch signal, and reverse signal.

Speaker Test

Checks the connection of each speaker using a test tone.

Auto Climate Control

Turns all A/C screens on display and A/C switch indicator lamp on.

Navigation

Display Longitude &
Latitude

Display the map.Use the joystick to adjust position. Longitude and latitude
will be displayed.

Speed Calibration

Under ordinary conditions, the navigation system distance measuring func-
tion will automatically compensate for minute decreases in wheel and tire
diameter caused by tire wear or low pressure.Speed calibration immediately
restores system accuracy in cases such as when distance calibration is
needed because of the use of tire chains in inclement weather.

Angle Adjustment

Corrects difference between actual turning angle of a vehicle and turning
angle of the car mark on the display.

Initialize Location

This mode is for initializing the current location. Use when the vehicle is
transported a long distance on a trailer, etc.

History of Errors

Diagnosis results previously stored in the memory (before turning ignition
switch ON) are displayed in this mode. Time and location when/where the
errors occurred are also displayed.

Rear View Camera

Changes position of the aiming line overlapped on the rear view image.
