Infiniti F50. Manual - part 164

AUDIO

AV-21

C

D

E

F

G

H

I

J

L

M

A

B

AV

16 (Y)

Ground

Communica-
tion signal (+)

Input/

output

ON

-

System does not
work properly.

52 (R/L)

51 (R/W)

CD sound
signal (LH)

Input

ON

Play  CD.

CD sound is not
heard from
speaker LH.

54 (LG)

53 (PU)

CD sound
signal (RH)

Input

ON

Play  CD.

CD sound is not
heard from
speaker RH.

55

-

Shield ground
(signal)

-

-

-

-

-

56

-

Shield ground
(signal)

-

-

-

-

-

58 (Y)

Ground

Communica-
tion signal
(CHG REQ)

Input

ON

Insert/eject CD.

CD auto changer
operation is not
possible.

59 (L)

Ground

Communica-
tion signal
(CHG-HU)

Input

ON

Insert/eject CD.

CD auto changer
operation is not
possible.

60 (G)

Ground

Communica-
tion signal
(HU-CHG)

Output

ON

Press the CD
switch.

CD auto changer
operation is not
possible.

Terminal No.

Item

Signal

input/

output

Condition

Voltage

Example of symp-

tom

+

-

Ignition

switch

Operation

SKIA0175E

SKIA0177E

SKIA0177E

SKIA0196E

SKIA0197E

SKIA0198E

AV-22

AUDIO

NOTE:
1.

With NAVI and for Canada with rear control switch.

2.

Without NAVI.

71 (R/L)

Ground

Illumination
signal

Input

OFF

Lighting switch
is ON (1st posi-
tion).

Battery voltage

Audio unit illumi-
nation does not
come on when
lighting switch is
ON (1st position).

Turn lighting
switch OFF.

Approx. 3.0V or less

72 (L/OR)

Ground

ACC power

Input

ACC

-

Battery voltage

Audio unit opera-
tion is not possi-
ble.

73 (SB)

Ground

Battery power

Input

OFF

-

Battery voltage

Cassette tape
player operation is
not possible.

75 (P/L)

Ground

Radio
antenna amp.
ON signal

Output

ON

-

Approx.10V or more

Receiving status
of radio broadcast
becomes bad.

76 (SB)

Note1

(LG)

Note2

Ground

Illumination
control signal

Input

ON

Illumination
control switch is
operated by
lighting switch
in 1st position.

Changes between approx. 0 and

approx. 12V.

Audio unit illumi-
nation cannot be
controlled.

78

-

Shield
(Audio sound
signal)

-

-

-

-

-

80 (BR)

79 (Y)

Audio sound
signal (LH)

Output

ON

Play cassette
tape.

Audio sound is not
heard from
speaker LH.

82 (B)

81 (W)

Audio sound
signal (RH)

Output

ON

Play cassette
tape.

Audio sound is not
heard from
speaker RH.

Terminal No.

Item

Signal

input/

output

Condition

Voltage

Example of symp-

tom

+

-

Ignition

switch

Operation

SKIA0177E

SKIA0177E

AUDIO

AV-23

C

D

E

F

G

H

I

J

L

M

A

B

AV

Terminals and Reference Value for CD Auto Changer

EKS0012U

Terminal No.

Signal

name

Signal

input/

output

Condition

Voltage

Example of symptom

+

-

Ignition

switch

Operation

2 (R/L)

1 (R/W)

CD sound
signal (LH)

Output

ON

Play CD.

CD sound is not
heard from speaker
LH.

4 (LG)

3 (PU)

CD sound
signal (RH)

Output

ON

Play CD.

CD sound is not
heard from speaker
RH.

6

-

Shield
(CD sound
signal)

-

-

-

-

-

8 (Y)

Ground

Communi-
cation sig-
nal (REQ)

Output

ON

Insert/eject t CD.

CD auto changer
operation is not pos-
sible.

9 (L)

Ground

Communi-
cation sig-
nal (TXD)

Output

ON

Insert/eject CD.

CD auto changer
operation is not pos-
sible.

10 (G)

Ground

Communi-
cation sig-
nal (RXD)

Input

ON

Press the CD
switch.

CD auto changer
operation is not pos-
sible.

12

(SB)

Ground

Battery
power

Input

OFF

-

Battery voltage

CD auto changer
operation is not pos-
sible.

13

(SB)

Ground

Illumination
control sig-
nal

Input

ON

illumination con-
trol switch is oper-
ated by lighting
switch in 1st posi-
tion

 Changer between approx. 0 and

approx.12V

-

SKIA0177E

SKIA0177E

SKIA0196E

SKIA0197E

SKIA0198E

AV-24

AUDIO

Terminals and Reference Value for Rear Control Switch

EKS001JO

Terminals and Reference Value for Rear Control Cancel Switch

EKS006H5

Self-Diagnosis Function

EKS006RK

DESCRIPTION

●

Diagnosis function consists of the self-diagnosis mode, and the “CONFIRMATION/ADJUSTMENT” mode.

●

Self-diagnosis mode checks for connection among audio unit, and CD auto changer and analyzes each
unit, then displays the results.

●

“CONFIRMATION/ADJUSTMENT” function analyzes each speaker.(without navigation system)

14 (R/

L)

Ground

Illumination
signal

Input

OFF

Lighting switch is
ON (1st position)

Battery voltage

-

Turn lighting
switch OFF

Approx. 3.0V or less

-

15 (B)

Ground

Ground

-

ON

-

Approx. 0V

-

16 (L/

OR)

Ground

ACC power

Input

ACC

-

Battery voltage

CD auto changer
operation is not pos-
sible.

Terminal No.

Signal

name

Signal

input/

output

Condition

Voltage

Example of symptom

+

-

Ignition

switch

Operation

TERMINALS

ITEM

CONDITION

DATA (DC)

(+)

(–)

TERMINAL

WIRE

COLOR

Ignition

switch

Operation

1

L/Y

Ground

ACC Power

ACC

Rear control cancel

switch is ON

(position ON)

Ground battery voltage

12

B

Ground

Ground

ON

—

Approx. 0V

10

Y

Ground

Rear control switch
communication sig-
nal

ON

Operate the rear
control switch.

SKIA0199J

Terminal No.

Signal

name

Signal

input/

output

Condition

Voltage

Example of symptom

+

-

Ignition

switch

Operation

3 (G)

Ground

Acc power

Output

ACC

Rear control can-
cel switch is ON
(position ON)

Battery voltage

-

Rear control can-
cel switch is OFF
(position CAN-
CEL)

Approx. 0V

-

4 (P/B)

Ground

Acc power

Input

ACC

-

Battery voltage

Rear control switch
operation does not
work.
