Infiniti I35 (A33). Manual - part 562

Special Service Tool

NHMA0002

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number
(Kent-Moore No.)
Tool name

Description

KV10115801
(J38956)
Oil filter cap wrench

NT375

Removing oil filter
a: 64.3 mm (2.531 in)

Commercial Service Tool

NHMA0003

Tool name
(Kent-Moore No.)

Description

Belt tension gauge
(BT3373-F)

AMA126

Checking drive belt tension

IDX

PREPARATION

Special Service Tool

MA-3

NHMA0004

General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their INFINITI dealers do them.
OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

Item

Reference page

Tires

Check the pressure with a gauge, including the spare, at least once a month
and always prior to a long distance trips. Adjust to the specified pressure if
necessary. Check carefully for damage, cuts or excessive wear.

—

Wheel nuts

When checking the tires, make sure no nuts are missing, and check for any
loose nuts. Tighten if necessary.

—

Windshield

Clean the windshield on a regular basis. Check the windshield at least every
six months for cracks or other damage. Repair as necessary.

—

Tire rotation

Tires should be rotated every 12,000 km (7,500 miles).

MA-23

Wheel alignment and
balance

If the vehicle pulls to either side while driving on a straight and level road, or
if you detect uneven or abnormal tire wear, there may be a need for wheel
alignment. If the steering wheel or seat vibrates at normal highway speeds,
wheel balancing may be needed.

MA-21,

SU-7, “Preliminary

Inspection”

SU-19, “Preliminary

Inspection”

Windshield wiper
blades

Check for cracks or wear if they do not wipe properly.

—

Doors and engine
hood

Check that all doors and the engine hood operate smoothly as well as the
trunk lid and back hatch. Also make sure that all latches lock securely. Lubri-
cate if necessary. Make sure that the secondary latch keeps the hood from
opening when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check
lubrication frequently.

MA-25

Lamps

Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and
other lamps are all operating properly and installed securely. Also check
headlamp aim.

—

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.

Item

Reference page

Warning lamps and
chimes

Make sure that all warning lamps and chimes are operating properly.

—

Windshield wiper and
washer

Check that the wipers and washer operate properly and that the wipers do
not streak.

—

Windshield defroster

Check that the air comes out of the defroster outlets properly and in suffi-
cient quantity when operating the heater or air conditioner.

—

Steering wheel

Check that it has the specified play. Be sure to check for changes in the
steering condition, such as excessive play, hard steering or strange noises.
Free play: Less than 35 mm (1.38 in)

—

Seats

Check seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every
position. Check that the head restrains move up and down smoothly and that
the locks (if equipped) hold securely in all latched positions. Check that the
latches lock securely for folding-down rear seatbacks.

—

Seat belts

Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters
and retractors) operate properly and smoothly and are installed securely.
Check the belt webbing for cuts, fraying, wear or damage.

MA-26,

RS-8, “Seat Belt Inspec-

tion”

GENERAL MAINTENANCE

MA-4

Item

Reference page

Accelerator pedal

Check the pedal for smooth operation and make sure the pedal does not
catch or require uneven effort. Keep the floor mats away from the pedal.

—

Brakes

Check that the brake does not pull the vehicle to one side when applied.

—

Brake pedal and
booster

Check the pedal for smooth operation and make sure it has the proper dis-
tance under it when depressed fully. Check the brake booster function. Be
sure to keep floor mats away from the pedal.

BR-11, “Brake Pedal and

Bracket” and BR-19,

“Brake Booster”

Parking brake

Check that the lever has the proper travel and make sure that the vehicle is
held securely on a fairly steep hill when only the parking brake is applied.

BR-34, “Parking Brake

Control”

Automatic transaxle
“Park” mechanism

Check that the lock release button on the selector lever operates properly
and smoothly. On a fairly steep hill check that the vehicle is held securely
with the selector lever in the “P” position without applying any brakes.

—

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

Item

Reference page

Windshield washer
fluid

Check that there is adequate fluid in the tank.

—

Engine coolant level

Check the coolant level when the engine is cold.

MA-14

Radiator and hoses

Check the front of the radiator and clean off any dirt, insects, leaves, etc.,
that may have accumulated. Make sure the hoses have no cracks,
deformation, deterioration or loose connections.

—

Brake fluid level

Make sure that the brake fluid level is between the “MAX” and “MIN” lines on
the reservoir.

MA-23

Battery

Check the fluid level in each cell. It should be between the “MAX” and “MIN”
lines. Vehicles operated in high temperatures or under severe conditions
require frequent checks of the battery fluid level.

—

Engine drive belts

Make sure that no belt is frayed, worn, cracked or oily.

MA-13

Engine oil level

Check the level on the dipstick after parking the vehicle on a level spot and
turning off the engine.

MA-16

Power steering fluid
level and lines

Check the level on the dipstick with the engine off. Check the lines for
improper attachment, leaks, cracks, etc.

MA-24

Automatic transaxle
fluid level

Check the level on the dipstick after putting the selector lever in “P” with the
engine idling.

MA-20

Exhaust system

Make sure there are no loose supports, cracks or holes. If the sound of the
exhaust seems unusual or there is a smell of exhaust fumes, immediately
locate the trouble and correct it.

MA-20

Underbody

The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these
substances, otherwise rust will form on the floor pan, frame, fuel lines and
around the exhaust system. At the end of winter, the underbody should be
thoroughly flushed with plain water, being careful to clean those areas where
mud and dirt can easily accumulate.

—

Fluid leaks

Check under the vehicle for fuel, oil, water or other fluid leaks after the
vehicle has been parked for a while. Water dripping from the air conditioner
after use is normal. If you should notice any leaks or gasoline fumes are
evident, check for the cause and correct it immediately.

—

IDX

GENERAL MAINTENANCE

MA-5

NHMA0005

Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.

Schedule 1

Follow Periodic Maintenance Schedule 1 if the driving habits frequently
include one or more of the following driving conditions:

Repeated short trips of less than 5 miles (8 km).

Repeated short trips of less than 10 miles (16 km) with outside tempera-
tures remaining below freezing.

Operating in hot weather in stop-and-go “rush hour” traffic.

Extensive idling and/or low speed driving for long distances, such as
police, taxi or door-to-door delivery use.

Driving in dusty conditions.

Driving on rough, muddy, or salt spread roads.

Towing a trailer, using a camper or a car-top carrier.

Emission Control
System Maintenance

MA-7

Chassis and Body
Maintenance

MA-8

Schedule 2

Follow Periodic Maintenance Schedule 2 if none of driving conditions shown
in Schedule 1 apply to the driving habits.

Emission Control
System Maintenance

MA-9

Chassis and Body
Maintenance

MA-10

PERIODIC MAINTENANCE

MA-6
