Infiniti I35 (A33). Manual - part 506
QUICK REFERENCE CHART: I35
2004
Engine model
VQ35DE
Firing order
1-2-3-4-5-6
Idle speed
rpm
A/T
(in “N” position)
675±50
Ignition timing (degree BTDC at idle speed)
A/T: 15°±5°
CO% at idle
Idle mixture screw is preset and
sealed at factory.
Drive belt deflection adjustment (Cold)
mm (in)
Used belt
Deflection of
new belt
Limit
Deflection
after
adjustment
Alternator and air conditioner compres-
sor
7 (0.28)
4.2 - 4.6
(0.165 - 0.181)
3.7 - 4.1
(0.146 - 0.161)
Power steering oil pump
11 (0.43)
7.3 - 8
(0.287 - 0.315)
6.5 - 7.2
(0.256 - 0.283)
Applied pushing force
N (kg, lb)
98 (10, 22)
Drive belt tension adjustment (Cold)
N (kg, lb)
Used belt
New belt
Limit
After adjust-
ment
Alternator and air conditioner compres-
sor
294 (30, 66)
730 - 818
(74.5 - 83.5,
164 - 184)
838 - 926
(85.5 - 94.5,
188 - 208)
Power steering oil pump
196 (20, 44)
495 - 583
(50.5 - 59.5,
111 - 131)
603 - 691
(61.5 - 70.5,
136 - 155)
Applied pushing force
—
Radiator cap relief pressure
kPa (kg/cm
2
, psi)
78 - 98 (0.8 - 1.0, 11 - 14)
Cooling system leakage testing pressure
kPa (kg/cm
2
, psi)
157 (1.6, 23)
Compression pressure
kPa (kg/cm
2
, psi)/rpm
Standard
1,275 (13.0, 185)/300
Minimum
981 (10.0, 142)/300
High tension cable resistance
k
Ω
—
Spark plug
Type
Standard
PLFR5A-11
Hot
PLFR4A-11
Cold
PLFR6A-11
Gap (Nominal) mm (in)
1.1 (0.043)
Tire size
P225/50R17, P215/55R17
Camber
Degree minute
(Decimal degree)
Minimum
−1°00
′
(−1.00°)
Nominal
−0°15
′
(−0.25°)
Maximum
0°30
′
(0.50°)
Left and right difference
45
′
(0.75°) or less
Caster
Degree minute
(Decimal degree)
Minimum
2°00
′
(2.00°)
Nominal
2°45
′
(2.75°)
Maximum
3°30
′
(3.50°)
Left and right difference
45
′
(0.75°) or less
Total toe-in
Minimum
0 (0)
Distance (A − B)
mm (in)
Nominal
1 (0.04)
Maximum
2 (0.08)
Angle (left plus right)
Degree minute
(Decimal degree)
Minimum
0
′
(0)
Nominal
6
′
(0.10°)
Maximum
12
′
(0.20°)
Wheel turning angle (Full turn)
Minimum
29°30
′
(29.50°)
Inside
Degree minute
(Decimal degree)
Nominal
33°00
′
(33.00°)
Maximum
34°00
′
(34.00°)
Outside
Degree minute
(Decimal degree)
Nominal
28°30
′
(28.50°)
* Fuel, radiator coolant and engine oil full.
Spare tire, jack, hand tools and mats in designated positions.
Camber
Degree minute
(Decimal degree)
Minimum
−1°45
′
(−1.75°)
Nominal
−1°00
′
(−1.00°)
Maximum
−0°15
′
(−0.25°)
Total toe-in
Minimum
−3 (−0.12)
Distance (A − B)
mm (in)
Nominal
1 (0.04)
Maximum
5 (0.20)
Angle (left plus right)
Degree minute
(Decimal degree)
Minimum
−16
′
(−0.27°)
Nominal
5
′
30
″
(0.09°)
Maximum
26
′
(0.43°)
* Fuel, radiator coolant and engine oil full.
Spare tire, jack, hand tools and mats in designated positions.
Unit: mm (in)
Front brake
Pad wear limit
2.0 (0.079)
Rotor repair limit
22.0 (0.866)
Rear brake
Pad wear limit
1.5 (0.059)
Rotor repair limit
8.0 (0.315)
Pedal free height
167 - 174 (6.57 - 6.85)
Pedal depressed height*1
82.5 (3.248)
Parking brake
Number of notches*2
4 - 5
*1 Under force of 490 N (50 kg, 110 lb) with engine running
*2 At pulling force: 196 N (20 kg, 44 lb)
Unit
Liter
US measure
Coolant with reservoir
7.7
8-1/8 qt
Engine*
Drain and refill
With oil filter
4.0
4-1/4 qt
Without oil filter
3.7
3-7/8 qt
Dry engine (engine overhaul)
5.0
5-1/4 qt
Transaxle
A/T
RE4F04B
8.5
9 qt
Power steering system
1.1
1-1/8 qt
Air conditioning system
Refrigerant
0.50 kg
1.10 lb
Compressor oil
0.18
6.1 fl oz
* For further details, see “Changing Engine Oil” in MA section.
