Parts Requiring Angular Tightening
NHEM0001
I
Use an angle wrench [SST: KV10112100] for the final tighten-
ing of the following engine parts:
a)
Cylinder head bolts
b)
Main bearing cap bolts
c)
Connecting rod cap nuts
d)
Crankshaft pulley bolt
I
Do not use a torque value for final tightening.
I
The torque value for these parts are for a preliminary step.
I
Ensure thread and seat surfaces are clean and coated with
engine oil.
SEM164F
Liquid Gasket Application Procedure
NHEM0002
1.
Use a scraper to remove all traces of old liquid gasket from
mating surfaces and grooves. Also, completely clean any oil
from these areas.
2.
Apply a continuous bead of liquid gasket to mating surfaces.
(Use Genuine RTV silicone sealant or equivalent. Refer to
GI-53.)
I
Be sure liquid gasket diameter is as specified in this manual.
AEM080
3.
Apply liquid gasket around the inner side of bolt holes (unless
otherwise specified).
4.
Assembly should be done within 5 minutes after coating.
5.
Wait at least 30 minutes before refilling engine oil and engine
coolant.
