Infiniti I35 (A33). Manual - part 105





Commercial Service Tools

NHBR0004

Tool name

Description

1 Flare nut crowfoot
2 Torque wrench

NT360

Removing and installing each brake piping
a: 10 mm (0.39 in)/12 mm (0.47 in)

Brake fluid pressure
gauge

NT151

Measuring brake fluid pressure

GI

MA

EM

LC

EC

FE

AT

AX

SU

ST

RS

BT

HA

SC

EL

IDX

PREPARATION

Commercial Service Tools

BR-5

NHBR0005

NVH

T

roubleshooting

Chart

NHBR0005S01

Use

the

chart

below

to
help

you

find

the

cause

of
the

symptom.

If

necessary

,

repair

or
replace

these

parts.

Reference

page

BR-22, 26

BR-22, 26

BR-22, 26

BR-24, 30

BR-25, 31

NVH in AX section

NVH in AX section

NVH in SU section

NVH in SU section

NVH in SU section

NVH in ST section

Possible

cause

and

SUSPECTED

P

A

R

T

S

Pads - damaged

Pads - uneven wear

Shims damaged

Rotor imbalance

Rotor damage

Rotor runout

Rotor deformation

Rotor deflection

Rotor rust

Rotor thickness variation

DRIVE SHAFT

AXLE

SUSPENSION

TIRES

ROAD WHEEL

STEERING

Symptom

BRAKE

Noise

X

X

X

XXXXX

X

Shake

X

XXXXX

X

Shimmy

,

Judder

XXXX

X

X

X

XXXX

X

X:
Applicable

NOISE,

V

IBRATION

AND

HARSHNESS

(NVH)

T

ROUBLESHOOTING

NVH

T

roubleshooting

Chart

BR-6

SBR451D

Checking Brake Fluid Level

NHBR0006

I

Check fluid level in reservoir tank. It should be between Max
and Min lines on reservoir tank.

I

If fluid level is extremely low, check brake system for leaks.

I

Release parking brake lever and see if brake warning lamp
goes off. If not, check brake system for leaks.

SBR389C

Checking Brake Line

NHBR0007

CAUTION:

If leakage occurs around joints, retighten or, if necessary,
replace damaged parts.
1.

Check brake lines (tubes and hoses) for cracks, deterioration
or other damage. Replace any damaged parts.

2.

Check for oil leakage by fully depressing brake pedal while
engine is running.

SBR419C

Changing Brake Fluid

NHBR0008

CAUTION:

I

Refill with new brake fluid “DOT 3”.

I

Always keep fluid level higher than minimum line on res-
ervoir tank.

I

Never reuse drained brake fluid.

I

Be careful not to splash brake fluid on painted areas; it
may cause paint damage. If brake fluid is splashed on
painted areas, wash it away with water immediately.

1.

Clean inside of reservoir tank, and refill with new brake fluid.

2.

Connect a vinyl tube to each air bleeder valve.

3.

Drain brake fluid from each air bleeder valve by depressing
brake pedal.

4.

Refill until brake fluid comes out of each air bleeder valve.
Use same procedure as in bleeding hydraulic system to refill
brake fluid. Refer to “Bleeding Brake System”, BR-8.

Brake Burnishing Procedure

NHBR0036

Burnish the brake contact surfaces according to the following pro-
cedure after refinishing or replacing drums or rotors, after replac-
ing pads or linings, or if a soft pedal occurs at very low mileage.

CAUTION:

Only perform this procedure under safe road and traffic con-
ditions. Use extreme caution.
1.

Drive the vehicle on a straight smooth road at 50 km/h (31
MPH).

2.

Use medium brake pedal/foot effort to bring the vehicle to a
complete stop from 50 km/h (31 MPH). Adjust brake pedal/foot

GI

MA

EM

LC

EC

FE

AT

AX

SU

ST

RS

BT

HA

SC

EL

IDX

ON-VEHICLE SERVICE

Checking Brake Fluid Level

BR-7

pressure such that vehicle stopping time equals 3 to 5 sec-
onds.

3.

To cool the brake system, drive the vehicle at 50 km/h (31
MPH) for 1 minute without stopping.

4.

Repeat steps 1 to 3, 10 times or more to complete the burnish-
ing procedure.

SBR995

Bleeding Brake System

NHBR0009

CAUTION:

I

Carefully monitor brake fluid level at master cylinder dur-
ing bleeding operation.

I

Fill reservoir with new brake fluid “DOT 3”. Make sure it is
full at all times while bleeding air out of system.

I

Place a container under master cylinder to avoid spillage
of brake fluid.

I

For models with ABS, turn ignition switch OFF and dis-
connect ABS actuator connectors or battery ground cable.

SBR419C

I

Bleed air in the following order.
Right rear brake

,

Left front brake

,

Left rear brake

,

Right

front brake

1.

Connect a transparent vinyl tube to bleed valve.

2.

Fully depress brake pedal several times.

3.

With brake pedal depressed, open bleed valve to release air.

4.

Close bleed valve.

5.

Release brake pedal slowly.

6.

Repeat steps 2. through 5. until clear brake fluid comes out of
bleed valve.

ON-VEHICLE SERVICE

Brake Burnishing Procedure (Cont’d)

BR-8
