MWI-70 < ECU DIAGNOSIS > COMBINATION METER 15 (B) Ground Ground — Ignition — 0 V 16 (B) Ground Meter control switch ground — Ignition — 0 V 21 (R) Ground Ignition signal Input Ignition — 12 V 22 (B) Ground Ground — Ignition — 0 V 24 (BR) Ground Communication signal → AMP.) Output Ignition — 25 (Y) Ground Communication signal → LCD) Input Ignition — 26 (R) Ground Vehicle speed signal Input Ignition Speedometer operated NOTE: 27 (O) Ground Parking brake switch signal Input Ignition Parking brake applied 0 V Parking brake released Terminal No. (Wire color) Description Condition Value (Approx.) + – Signal name Input/ Output JSNIA0028GB JSNIA0027GB JSNIA0012GB JSNIA0007GB |
