DRIVER SEAT CONTROL UNIT
MIR-19
< ECU DIAGNOSIS >
[WITH ADP]
C
D
E
F
G
H
I
J
K
M
A
B
MIR
N
O
P
*1
: A/T model
*2
: M/T model
*3
: The value at the position attained when the battery is connected is regarded as 32768.
TELESCO SW-FR
Telescopic switch
Forward
ON
Other than above
OFF
TELESCO SW-RR
Tilt switch
Backward
ON
Other than above
OFF
FORWARD SW
Seat back
Folded down
ON
Other than above
OFF
WALK-IN SW
Power walk-in switch
Pressed
ON
Other than above
OFF
FWD LIMIT SW
Seat sliding
Front edge
ON
Other than above
OFF
SEAT BELT SW
Seat belt
Fastened
ON
Other than above
OFF
DETENT SW
*1
A/T selector lever
P position
OFF
Other than above
ON
PARK BRAKE SW
*2
Parking brake
Applied
ON
Release
OFF
STARTER SW
Ignition position
Cranking
ON
Other than above
OFF
SLIDE PULSE
Seat sliding
Forward
The numeral value decreases
*3
Backward
The numeral value increases
*3
Other than above
No change to numeral value
*3
RECLN PULSE
Seat reclining
Forward
The numeral value decreases
*3
Backward
The numeral value increases
*3
Other than above
No change to numeral value
*3
LIFT FR PULSE
Seat lifter (front)
Up
The numeral value decreases
*3
Down
The numeral value increases
*3
Other than above
No change to numeral value
*3
LIFT RR PULSE
Seat lifter (rear)
Up
The numeral value decreases
*3
Down
The numeral value increases
*3
Other than above
No change to numeral value
*3
MIR/SEN RH U-D
Door mirror (passenger side)
Change between 3.4 (close to peak)
0.6 (close to valley)
MIR/SEN RH R-L
Door mirror (passenger side)
Change between 3.4 (close to left edge)
0.6 (close to right edge)
MIR/SEN LH U-D
Door mirror (driver side)
Change between 3.4 (close to peak)
0.6 (close to valley)
MIR/SEN LH R–L
Door mirror (driver side)
Change between 0.6 (close to left edge)
3.4 (close to right edge)
TILT SEN
Tilt position
Change between 1.2 (close to top)
3.4 (close to bottom)
TELESCO SEN
Telescopic position
Change between 3.4 (close to top)
0.8 (close to bottom)
Monitor Item
Condition
Value/Status
